1 Grosvenor Square AV and Lighting

• Apartment Number

• Conducted on

  Date

• Prepared by

Lighting

• Are all light fittings installed?

  Yes

  No

  N/A

• Are all lights controlled?

  Yes

  No

  N/A

• Have all lights been addressed?

  Yes

  No

  N/A

• Are all lights in the correct groups?

  Yes

  No

  N/A

• Is the lighting section complete?

  Yes

  No

Processor

• Has the correct lighting program been uploaded to slot 1?

  Yes

  No

• Has the correct AV program been uploaded to slot 2?

  Yes

  No

• Has the correct HVAC program been uploaded to slot 3?

  Yes

  No

• Is the time and date correct on the processor?

  Yes

  No

• Is the processor section complete?

  Yes

  No

Keypads

• Are all keypads installed and fixed to the wall in the correct locations?

  Yes

  No

• Are all keypads damage free? if no, please take a picture to show damage

  Yes

  No

• Are all keypads powered and addressed correctly?

  Yes

  No

• Press button 1 up, does this recall scene 1?

  Yes

  No

• Press button 1 down, does this recall scene 2?

  Yes

  No

• Press button 2 up, does this recall scene 3?

  Yes

  No

• Press button 2 down, does this turn off all room lights?

  Yes

  No

• Press button 3 up, this is for future blind operation

  OK

• Press button 3 down, this is for future blind operation

  OK

• Press and hold button 3 up, this will raise all lights

  Yes

  No

• Press and hold button 3 down, this will lower all lights

  Yes

  No

• By the front door only, press and hold button 1 up, this will turn on all lights in the apartment

  Yes

  No

• By the front door only, press and hold button 2 down, this will turn off all lights in the apartment

  Yes

  No

• Is the keypad section complete?

  Yes

  No

Touchpanel

• Are the touch panel(s) installed?

  Yes

  No

• Is the touch panel powered and connected to the processor?

  Yes

  No

  N/A

• Is the touch panel damage free? if no, please take a picture to show damage

  Yes

  No

  N/A

• Does the touch panel control the correct areas?

  Yes

  No

  N/A

• Is the touch panel section complete?

  Yes

  No

Doorbell

• Has the doorbell cable been terminated in the LCP?

  Yes

  No

• Does the doorbell ring the touchpanel?

  Yes

  No

• Is the doorbell section complete?

  Yes

  No

HVAC

• Has the network cable been connected to the switch?

  Yes

  No

  N/A

• Is the HVAC showing as online on the touch panel?

  Yes

  No

  N/A

• Do all areas control correctly with 2 way control?

  Yes

  No

  N/A

• Is the HVAC section complete?

  Yes

  No

Notes / Comments

• Please enter any notes or comments here

Sign Off

• Smartcomm Commissioning Engineer

• I confirm that the above checks have been carried out and everything is fully commissioned.

  Sign

• Core Group

• I confirm by signing below that this apartment is fully commissioned by Smartcomm Ltd. Any further works to be carried out in this apartment will be subject to a call out fee and instruction to proceed.

  Sign

• Other Signature if required

• Please enter name of company

• Add signature

  Sign
