Preflight
Select suitable flight area (Size, Obstacles) Check wind speed Demarcate area
Setup Mavinci Connector (Base) where it will have clear line of site during the flight. Note Battery Level
Connector Battery Level: Number:%:volts
Connect Toughbook to the connector and start base station observations
Turn on Remote Control. Red - Manual, Yellow - Automatic
R.C Battery Level: volts
Assemble UAV, including fully charged battery (Note Level) and EMPTY SD Card. Complete Balance Check and check all flaps are moving freely.
UAV Battery Levels: Number:%:volts
Create flight session start with connection to UAV and set AOI
Check Position of UAV on screen, Rotate plan 3D to ensure flight is above terrain
Send Flight to Plane (Flight path should turn pink). Tap Flight
Switch RC to. Red - Autopilot, Yellow - Automatic.
Launch UAV into wind
Post Flight
After Landing, Red - Manual, Yellow - Automatic
Copy on-board photo logs
Shut everything down and Note all battery levels
Connector Battery Levels: Number:%:volts
R.C Battery Level: volts
UAV Battery Levels: Number:%:volts
Disassemble all equipment
