PV Survey

• Site conducted

  Select

• Conducted on

  Date

• Prepared by

• Location
  Address

• Property type

  House

  Bungalow

  Flat

  Maisonette

• Property detachment

  Select Detached Semi-detached Mid-terraced End-terraced Ground floor flat Middle floor flat Top floor flat

  • Detached
  • Semi-detached
  • Mid-terraced
  • End-terraced
  • Ground floor flat
  • Middle floor flat
  • Top floor flat

• Age of property

• Domestic or commercial:

  Domestic

  Commercial

• Is the property listed or in a conservation area:

  Yes

  No

• Are there any other planning issues to be considered

  Yes

  No

• List detail of issues to be considered:

• Is the current roof lining under an active warranty?

  Yes

  No

• Provide details of warranty:

• Will any form of protected species be disturbed by the installation process?

  Yes

  No

• Provide details

• New Build or Retro-fit:

  New Build

  Retro-fit

• Location of electric meter:

• Type of electric meter

  Analogue

  Digital

• Image of electric meter

  Media

• Location of electric distribution board

• Make of electric distribution board

• Are there any spare breakers:

  Yes

  No

• Is there a form of isolation:

  Yes

  No

• General condition of the electrical installation:

  Good

  Fair

  Poor

• Image of electric distribution board

  Media

• Is main earthing and bonding in place?

  Yes

  No

• On or Off grid?

  On

  Off

• DNO

  Select Western Power Scottish and southern electricity UK power networks SP energy networks

  • Western Power
  • Scottish and southern electricity
  • UK power networks
  • SP energy networks

• Electric supplier:

• Cost of electricity per kwh:

• Image of electricity bill

  Media

External

• General condition of roof:

  Good

  Fair

  Poor

  N/A

• Roof covering:

  Tiles

  Slate

  Flat

  Thatch

• Is the property in an exposed location:

  Yes

  No

• Any overhanging power cables:

  Yes

  No

• Width of building (m)

• Depth of building (m)

• Height to guttering (m)

• Height to ridge (m)

Internal

• Is there a loft present

  Yes

  No

  Loft conversion/room in roof

• Is loft accessible

  Yes

  No

• Distance from ceiling to ridge (m)

• Pitch of Roof (deg)

• Image of loft

  Media

• Image of loft 2

  Media

Property Orientation

• Orientation of front elevation

  North

  East

  West

  South

• Image of compass providing exact orientation

  Media

• Image of front elevation

  Media

• Orientation of rear elevation

  North

  East

  West

  South

• Image of compass providing exact orientation

  Media

• Image of rear elevation

  Media

• Orientation of left elevation

  North

  East

  West

  South

• Image of compass providing exact orientation

  Media

• Image of left elevation

  Media

• Orientation of right elevation

  North

  East

  West

  South

• Image of compass providing exact orientation

  Media

• Image of right elevation

  Media

Roof

• Roof elevation where panels will be fitted:

  Front elevation

  Rear elevation

  Left elevation

  Right elevation

• Area of roof availible (m2):

• Any roof vents, flues or soil stacks present:

  Yes

  No

• Any shading concerns:

  Yes

  No

• Any future shading concerns:

  Yes

  No

• Is there a chimney present:

  Yes

  No

• Is there a Velux window:

  Yes

  No

PV Panels

• System Output

  1.5kw - 4 x Panels

  2.4kw - 6 x Panels

• Design and Layout of Panels

  Portrait

  Landscape

  Combination of Both

• Sketch of proposed Design

  Media

Inverter and DC Isolation

• Proposed location of inverter:

• If timber-frame required for inverter - attic installation

• Location of DC isolation:

• Description of cable route from PV panels to DC isolation

AC isolation and Generation Meter

• Location of AC isolation

• Location of Generation Meter

• Description of cable run from Inverter to AC isolation

• Is there sufficient roof area (m2) to house 4/6 PV panels:

  Yes

  No

• Is there a suitable location for the Inverter:

  Yes

  No

• Can electric cables be run from panels to inverter:

  Yes

  No

• Is there a suitable location for the generation meter - close to the electrical distribution board:

  Yes

  No

• Can electric cables be run from the inverter to the generation meter:

  Yes

  No

• Is there a spare breaker breaker in the electrical distribution board:

  Yes

  No

• Is there suitable isolation:

  Yes

  No

• Can scaffolding be safely erected:

  Yes

  No

• Is a scaffolding permit required

  Yes

  No

• Is there appropriate access for scaffolding?

  Yes

  No

• Can scaffolding be erected safely?

  Yes

  No
