Rigging Hardware & Slings Inspection
undefined
INSPECTION FREQUENCY PER ASME B30.26 A VISUAL INSPECTION SHALL BE PERFORMED BY THE USER OR DESIGNATED PERSON EACH DAY BEFORE THE RIGGING HARDWARE IS USED. A PERIODIC INSPECTION SHALL BE PERFORMED BY A DESIGNATED PERSON, AT LEAST ANNUALLY. THE RIGGING HARDWARE SHALL BE EXAMINED AND A DETERMINATION MADE AS TO WHETHER THEY CONSTITUTE A HAZARD. WRITTEN RECORDS ARE NOT REQUIRED. SEMI-PERMANENT AND INACCESSIBLE LOCATIONS WHERE FREQUENT INSPECTIONS ARE NOT FEASIBLE SHALL HAVE PERIODIC INSPECTIONS PERFORMED.
-
Rigging Hardware Serial Number:
-
Rigging Hardware Serial Number:
-
Photo:
-
Location:
-
REJECTION CRITERIA PER ASME B30.26-2014
-
MISSING OR ILLEGIBLE MANUFACTURER’S NAME OR TRADEMARK AND/OR RATED LOAD IDENTIFICATION (OR SIZE AS REQUIRED).
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
A 10% OR MORE REDUCTION OF THE ORIGINAL DIMENSION
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
EXCESSIVE NICKS, GOUGES, PITTING AND CORROSION
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
BENT, TWISTED, DISTORTED, STRETCHED, ELONGATED, CRACKED OR BROKEN LOAD BEARING COMPONENTS
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
INDICATIONS OF HEAT DAMAGE INCLUDING WELD SPATTER OR ARC STRIKES, EVIDENCE OF UNAUTHORIZED WELDING
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
LOOSE OR MISSING NUTS, BOLTS, COTTER PINS, SNAP RINGS, OR OTHER FASTENERS AND RETAINING DEVICES
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
UNAUTHORIZED REPLACEMENT COMPONENTS OR OTHER VISIBLE CONDITIONS THAT CAUSE DOUBT AS TO THE CONTINUED USE OF THE SLING
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
ADDITIONALLY INSPECT WIRE ROPE CLIPS FOR:
-
1. INSUFFICIENT NUMBER OF CLIPS<br>2. INCORRECT SPACING BETWEEN CLIPS<br>3. IMPROPERLY TIGHTENED CLIPS<br>4. INDICATIONS OF DAMAGED WIRE ROPE OR WIRE ROPE SLIPPAGE<br>5. IMPROPER ASSEMBLY
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
ADDITIONALLY, INSPECT WEDGE SOCKETS FOR:
-
1. INDICATIONS OF DAMAGED WIRE ROPE OR WIRE ROPE SLIPPAGE<br>2. IMPROPER ASSEMBLY
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
ADDITIONAL REJECTION CRITERIA PER ASME B30.10 - HOOKS:
-
ANY VISIBLY APPARENT BEND OR TWIST FROM THE PLANE OF THE UNBENT HOOK
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
ANY DISTORTION CAUSING AN INCREASE IN THROAT OPENING OF 5%, NOT TO EXCEED 1/4”
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
MISSING OR ILLEGIBLE RATED LOAD IDENTIFICATION.
-
Notes:Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
MISSING OR ILLEGIBLE HOOK MANUFACTURER’S IDENTIFICATION OR SECONDARY MFG. IDENTIFICATION
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
Rigging Hardware & Sling Inspection
Inspection of Slings
-
INSPECTION FREQUENCY PER ASME B30.9
A VISUAL INSPECTION FOR DAMAGE SHALL BE PERFORMED BY THE USER OR DESIGNATED PERSON EACH DAY OR SHIFT THE SLING IS USED. A COMPLETE INSPECTION FOR DAMAGE SHALL BE PERFORMED PERIODICALLY BY A DESIGNATED PERSON, AT LEAST ANNUALLY.
WRITTEN RECORDS OF MOST RECENT PERIODIC INSPECTION SHALL BE MAINTAINED.
Sling Serial Number:
-
Sling Serial Number:
-
Photo:
-
Location:
-
REJECTION CRITERIA PER ASME B30.9
MISSING OR ILLEGIBLE SLING IDENTIFICATION; EVIDENCE OF HEAT DAMAGE; SLINGS THAT ARE KNOTTED; FITTINGS THAT ARE PITTED, CORRODED, CRACKED, BENT, TWISTED, GOUGED, OR BROKEN; OTHER CONDITIONS, INCLUDING VISIBLE DAMAGE, THAT CAUSE DOUBT AS TO THE CONTINUED USE OF THE SLING.
WIRE ROPE SLINGS
-
EXCESSIVE BROKEN WIRES, FOR STRAND-LAID AND SINGLE PART SLINGS, TEN RANDOMLY DISTRIBUTED BROKEN WIRES IN ONE ROPE LAY OR FIVE BROKEN WIRES IN ONE STRAND IN ONE ROPE LAY
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
SEVERE LOCALIZED ABRASION OR SCRAPING, KINKING, CRUSHING, BIRDCAGING
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
ANY OTHER DAMAGE RESULTING IN DAMAGE TO THE ROPE STRUCTURE
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
SEVERE CORROSION OF THE<br>ROPE OR END ATTACHMENTS
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
CHAIN SLINGS
-
CRACKS OR BREAKS
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
EXCESSIVE WEAR, NICKS OR GOUGES
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
STRETCHED CHAIN LINKS OR COMPONENTS
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
BENT, TWISTED OR DEFORMED CHAIN LINKS OR COMPONENTS
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
EXCESSIVE PITTING OR CORROSION
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
LACK OF ABILITY OF CHAIN OR COMPONENTS TO HINGE FREELY
-
Notes: Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
WELD SPATTER
-
Notes:
WEB SLINGS
-
ACID OR CAUSTIC BURNS
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
MELTING OR CHARRING OF ANY PART OF THE SLING
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
HOLES, TEARS, CUTS, ABRASIVE WEAR OR SNAGS THAT EXPOSE THE CORE YARNS
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
BROKEN OR WORN STITCHING IN LOAD BEARING SPLICES
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
EXCESSIVE ABRASIVE WEAR
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
DISCOLORATION AND BRITTLE OR STIFF AREAS ON ANY PART OF THE SLING, WHICH MAY MEAN CHEMICAL OR ULTRAVIOLET / SUNLIGHT DAMAGE
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
ROUND SLINGS
-
ACID OR CAUSTIC BURNS
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
EVIDENCE OF HEAT DAMAGE
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
HOLES, TEARS, CUTS, ABRASIVE WEAR OR SNAGS THAT EXPOSE THE CORE YARNS
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
BROKEN OR DAMAGED CORE YARNS
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
WELD SPATTER THAT EXPOSES CORE YARNS
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
DISCOLORATION AND BRITTLE OR STIFF AREAS ON ANY PART OF THE SLINGS, WHICH MAY MEAN CHEMICAL OR OTHER DAMAGE
-
Equipment MUST be taken "Out Of Service" until repair/replacement can be performed.
-
