Title Page
-
Site/Building Name
-
Type of Site Surveyed
-
Photo of Site Surveyed
-
Conducted on
-
Conducted by
-
Location
Health & Safety
Access and Egress
-
Are there any issues with site access and egress?
-
Specify the issues
-
Are there any size/weight limitations?
-
Is there pedestrian access?
-
Is there an emergency access?
-
Is Fire risk assessment avaialble?
-
is there an emergency plan in place?
-
is there an existing lighting protection system?
-
Are there any overhead powerlines?
Mechanical installation
Roof information
-
Roof type
-
Roof Material Type
-
Roof Construction
-
Roof height
-
Roof length
-
Roof slope or pitch
-
Roof orientation
-
Roof azimuth
-
Other roof measurement(s) if any
-
Internal roof length
-
Internal roof width
-
Internal roof details
-
Is there any shading concern?
-
Level of shading
-
Upload photos
Rafting Spacings
-
What's the rafting space?
DC cable
-
DC cable route
-
DC cable distance
AC cable
-
AC cable route
-
AC cable distance
Electrical side
Main incomer from DNO
-
Upload picture
Main meter
-
MPAN
-
Serial Number
-
CT ratio
Main Distribution Board
-
picture of MDB
-
Spare ways in MDB
PVDB(if required)
-
Space for PVDB
Inverter
-
Potential inverter location(s) on the site
-
Space for inverter
-
Monitoring Network Type
Main AC connection point
-
Phase type
-
Fuse rating (in amps)
-
Photo(s) of main AC connection point
Scaffold/Plant side
-
What is the height of the building?
-
How old is the building?
Location of Scaffold
-
Ground conditions
-
Scaffolding length
-
Scaffolding height
-
Scaffolding requirement
-
Scaffolding access tower
-
Door/ walkways
Space for Forklift/Scissor lift
-
Is the road/floor suitable?
-
Ground condition
-
Machine size
-
Platform working height
-
Photos of machine requirement
