Enhancement QC (DSCR Installation)

• Block Name/Site Address

• Name of Installer/s

• Date of Inspection

  Date

• Inspected by

• Document No.

Details

• S.I.D Block I.D

• Live or Retro Site Visit

  Live Visit

  Retro Visit

• Existing System Type

  Shared Dish

  I.R.S

  S.C.R

  M.A.T.V

• Number of Head-ends Upgraded

• Headends Internal or External

  Internal

  External

• Location Of Headends

  External Cabinet

  Riser Cupboard

  Loftspace

  Plant Room

  Other

• Where is Head-end?

DSCR Installation

• Switch Mounting?

• How was DSCR integrated?

  2 way splitter

  In Cascade

• Is all equipment mounted securely?

  Yes

  No

  N/A

• Correct amount of DSCR switches installed?

  Yes

  No

  N/A

• Are all 75ohm Terminators present?

  Yes

  No

  N/A

• Are all 75ohm DC Blocked Terminators present?

  Yes

  No

  N/A

• Are DC blockers present?

  Yes

  No

  N/A

• Why have DC blockers not been fitted?

• Is there a PSU plugged in and connected to DSCR?

  Yes

  No

  N/A

• Is PSU secured correctly?

  Yes

  No

  N/A

• Has a 4 way extension socket been used?

  Yes

  No

• Are Power Inserters Required?

  Yes

  No

• Are all switches correctly earth bonded to SKY specification?

  Yes

  No

  N/A

• Was a Cabinet installed?

  Yes

  No

• Was Cabinet required?

  Yes

  No

  N/A

• Is all cabling that has been fitted neatly loomed?

  Yes

  No

  N/A

• If Cabinet, have grommets been fitted to protect cables rubbing on entry holes?

  Yes

  No

  N/A

• Block name and H/E No: been written on backboard?

  Yes

  No

  N/A

• Have all the correct photos been uploaded to S.I.D

  Yes

  No

  N/A

DSCR switches installed (scan barcodes if possible)

• Please Scan all DSCR switches that have been installed

DSCR

• Serial Number

Signal Readings

• Was a Commissioning Certificate uploaded to S.I.D

  Yes

  No

  N/A

• Was commissioning sheet filled out correctly?

  Yes

  No

  N/A

• After checking signal levels, do they correspond with installers record?

  Yes

  No

  N/A

• Are signal levels within SKY Specification?

  Yes

  No

  N/A

Health & Safety

• If Live visit, did the engineer use appropriate P.P.E?

  Yes

  No

  N/A

• Is there evidence of W.A.H kit being used (eyebolts beneath Cabs etc)

  Yes

  No

  N/A

• Have the site work areas been left clean and tidy?

  Yes

  No

  N/A

Compliance

• Is upgrade compliant or Non compliant?

  Compliant

  Non Compliant

Notes

• Please add notes for any remedial works etc

• Additional photos of any remedial works etc

  Media

Survey

• Correct number of dwellings identified?

  Yes

  No

  N/A

• All headends located and identified correctly?

  Yes

  No

  N/A

• Block split or merged correctly?

  Yes

  No

  N/A

• Power source identified correctly?

  Yes

  No

  N/A

• DSCR integration designed correctly?

  Yes

  No

  N/A

• Please add additional notes regarding standard of survey

Signatures

• Installer 1

  Sign

• Supervisor

  Sign
