Information

  • Site conducted

  • Property name.

  • Inspector name.

  • Date.

  • Circuit chart No.

  • Building name.

Electrical Distribution Information

  • Distribution board location.

  • Distribution board ref number.

  • Distribution board make.

  • Distribution board type.

  • Distribution board supplied from.

  • Floor level.

  • Area covered.

  • Number of ways.

  • Local isolator rating (A)

  • Voltage rating (V)

  • Distribution board Prospective short circuit current (kA)

  • Distribution board Earth loop impedance (Ohms)

  • Main Residual Current Circuit Breaker.

  • Supply cable type and size.

  • Supply cable no of cores.

  • Approx route length (M)

  • Supplied from.

  • Supply protective device and rating (A)

  • Earthing conductor type and size (mm2)

  • Earthing conductor connection points.

  • Bonding conductor type and size (mm2)

  • Bonding conductor connection points.

Circuit Number, Equipment and Location Information

    Circuit Number - Number of Equipment Points and Type - Location (description) - Circuit Cable Size/Type - CPC Size/Type - Protective Device Rating/Type
  • Circuit number.

  • Equipment (State Number of points and Type).

  • Location (Room Number and Description).

  • Circuit Cable Size/Type.

  • CPC Size/Type.

  • Protective Device Rating/Type.

Inspection / Test Results

    Circuit Number and Test Results
  • Circuit number.

  • Ring circuits R1 (P) (ohms)

  • Ring circuits RN (N) (ohms)

  • Ring circuits R2 (CPC) (ohms)

  • All circuits R1+ R2 (ohms)

  • All circuits R2 (long lead method) (ohms)

  • Insulation Resistance (P-P) (Megohms)

  • Insulation Resistance (P-N) (Megohms)

  • Insulation Resistance (P-E) (Megohms)

  • Insulation Resistance (N-E) (Megohms)

  • Polarity correct.

  • Earth Fault Loop Impedance. (ohms)

  • RCD operation 0.5 x In (mS)

  • RCD operation 1 x In (mS)

  • RCD operation 5 x In (mS)

  • See observations sheet.
