Minor Cabling Works Site Survey.

• Site Name/Number:

• Site Address:
  Address

• ISG Job Number:

• Surveyor :

• Fault call ref number:

• Conducted on

  Date

• Brief description of works (note which data cab and position of new outlet):

• Number of engineers required:

• Number of hours required on site:

• Can work be carried out during normal working hours:

  Yes

  No

  N/A

• Note OOH access times (will nightshift need to be arranged if site is not 24hrs)

Telephone

• Is new phone outlets required

  Yes

  No

  N/A

• Number of new phone sockets required

• Note singles or doubles:

• Average length of 3pr 1308 in meters

• Additionals ( multicores, D.P., Krone strips ect)

Structured Cabling

• Is new Data cable required? If yes state what type.

  Cat 5e

  Cat 6

  Cat 6a

  No

• Number of new cables required:

• Average length of cable run in meters:

• Is new outlet required:

  Yes

  No

• Number required:

• Note if dual or single outlets or mixed

• Is new patch panel required:

  Yes

  No

• How many new patch panels?

• Are new patch leads required:

  Yes

  No

• 1m patch leads

• 3m patch leads

• Additional info:

Fibre

• Is new fibre required:

  Yes

  No

• Fibre core size

  Select 50/125 OM2 (up to 550m) 62/125 OM1 (up to 275m) 9/125 OS1 (above 550m) 50/125 OM3 (up to 550m)

  • 50/125 OM2 (up to 550m)
  • 62/125 OM1 (up to 275m)
  • 9/125 OS1 (above 550m)
  • 50/125 OM3 (up to 550m)

• Length of fibre cable

• Number of cores required

• Are new fibre trays required

  Yes

  No

• Number required

• Presentation type

  ST (round)

  SC (large square type)

  LC (small square type)

• Presentation of existing fibre tray (ST, LC, ECT)

  ST (round)

  SC (large square type)

  LC (small square type)

• Number of spare ways on existing fibre tray:

• Are new fibre patch leads required

  Yes

  No

• Number required

• Length of patch leads

• Connector type

  Select ST - ST ST - SC ST - LC SC - LC SC - SC LC - LC Other

  • ST - ST
  • ST - SC
  • ST - LC
  • SC - LC
  • SC - SC
  • LC - LC
  • Other

• Note other connector types required

Access Equipment

• Is special access equipment required, other than standard steps.

  Select Narrow aisle scissor (10m working height) Compact scissor (7.8m working height) Star 10 3 tier ladders 3.6m Pop up

  • Narrow aisle scissor (10m working height)
  • Compact scissor (7.8m working height)
  • Star 10
  • 3 tier ladders
  • 3.6m Pop up

• Note any access restrictions from back yard to shop floor (ramps ect) Should Hss deliver to front of store?

• Yes

  No

  N/A

• Notes (e.g. asbestos register present, noise/access restrictions, fire sealing required)

• Please take as many pictures as possible showing cabinets, outlet location, cable runs, possible obstructions and any site plans if none supplied ( hint: fire escape plans)

Media

• Cabinet location

  Media

• Description:

• Additional pictures:


• Additional pictures

  Media

• Description:

• Stock list is meant as a guide and is in no way a complete list. Any additional material required please list below.

Containment

• Do you require any containment

  Yes

  No

• 1 gang pvc back box

• 2 gang pvc back box

• white pvc trunking (3m length)

• What size

  25mm x16mm

  40mm x 25mm

  50mm x 50mm

• Note any bends & amounts required

• 20mm copex (per meter)

• 20mm glands white

• Colour of copex

  Black

  White

• 20mm white pvc conduit (3m length)

• Note any accessories & amounts required ( bends, couplers, adaptors ect)

• Additional materials:

Brand Rex (or preferred manufacturer)

• Do you require data cable materials? If so state what type.

  Cat 5e

  Cat 6

  Cat 6a

  No

• Low Smoke Cat5e (305m box)

• RJ45 Modules

• Half Width Blank 25x50

• Single Gang Faceplate

• Double Gang Faceplate

• 24 Way Patch Panel

• 1m Patch Leads

• State if colour other than white is required and amounts:

• 3m Patch Leads

• State if colour other than white is required and amounts:

• Additional materials:

Telephone

• Do you require Telephone materials

  Yes

  No

• 4pr 1308 cable (100m drum)

• LJU3/1A Master idc Single

• LJU3/1A Master idc Double

• Additional materials:

Fibre materials

• Do you require any fibre materials

  Yes

  No

• Length of fibre

• Fibre core size

  50/125 OM2 (up to 550m)

  62/125 OM1 (up to 275m)

  9/125 OS1 (above 550m)

  50/125 OM3 (up to 550m)

• Number of cores

• Number of connectors

• Connector type

  ST (round)

  SC (large square type)

  LC (small square type)

• Fibre trays (loaded)

• Number of fibre patch leads

• Length

• Connection type

  Select ST - ST ST - SC ST - LC SC - LC SC - SC LC - LC Other

  • ST - ST
  • ST - SC
  • ST - LC
  • SC - LC
  • SC - SC
  • LC - LC
  • Other

• Additional materials:
