Title Page

  • Customer Name

  • Customer address

  • Location
  • Customer Email address

System Installation Requirement

  • Check that the I&HAS has been installed and configured in accordance with the system design proposal (any deviations agreed in writing with the customer)

  • Check the I&HAS complies with current industry standards and is to a high standard of workmanship

  • Check that all interconnections are clearly labelled at the CIE, power supply units, expanders, remote key pads and junction boxes

  • Log resistance of detection interconnections or check continuity of bus wired interconnections

  • Check every detector for correct operation through to the CIE

  • Check that all batteries in CIE/PS(s) are marked with the date of installation

  • Log the current drawn by all power supplies with the I&HAS in quiescent and alarm states

  • Remove the mains supply and check that the battery voltage of all equipment is within the specified limits and the I&HAS operates normally

  • Check that there is adequate standby battery capacity to meet the requirements of the applicable standard the system was installed to

  • Check the operation of all WDs on system activation and when the hold-off voltage is removed from any self-powered device

  • Check the operation of all tamper devices

  • Check the area or volume of coverage of movement/vibration detectors including alignment of active beam detectors and any anti-masking or range reduction facilities (as appropriate)

  • Check the entry/exit route(s) for correct operation and record entry/exit times

  • Set system. Operate detection device(s) to check the resulting alarm condition(s) are notified correctly

  • Test correct operation of all ATS paths (where fitted) for correct receipt of signals at the ARC

  • If remote system checks or remote support is to be used, check correct synchronization of site-specific parameters between the I&HAS and secure computer

  • Show the customer the extent of the detection coverage and correct operation of the I&HAS including the operation of detectors and the use of HDs

  • Check that all documentation is correctly completed and customer documentation is left on site. Communication procedures with the ARC (if any) should be explained

  • Obtain customer signature acknowledging receipt and correct operation of key/codes to the I&HAS

  • Check that all surplus materials are removed from site and the premises left in a tidy condition

  • DMD Electrical, Fire and Security has direct access to the CIE

The Customer Confirms

  • that the Intruder Alarm System detailed in the above Systems Design Proposal has been installed to their satisfaction and that the system operation has been fully demonstrated and the necessary Keys/Codes/Fobs/ and User Manuals have been received.

  • Systems Design Proposal changes / part Acceptance or work to be undertaken by themselves is detailed below.

  • *Changes detailed above update your System Design Proposal (SDP) to become the ‘As-Fitted’ record.

  • *No changes have been made to the SDP therefore the SDP is the ‘As Fitted’ record.

  • Engineer Signature

  • Engineer Print Name

  • Date

  • Customer Name

  • Customer Signature
