Isolator Installation Check Sheet

• Project Name:

• Project No.:

• Date & Time

  Date

• Prepared by:

• Equipment Location:
  Address

• System:

Isolator a

• 1.1 Specified manufacture isolator used

  Yes

  No

  N/A

• 1.2. Isolator correct size (amps)

  Yes

  No

  N/A

• 1.3 Isolator used with the correct quantity of poles

  Yes

  No

  N/A

• 1.4 Isolator mounted at the correct height.

  Yes

  No

  N/A

• 1.5 Isolator mounted within suitable distance & line of sight of connected appliance.

  Yes

  No

  N/A

• 1.6 Suitable isolator mounting fixings used.

  Yes

  No

  N/A

• 1.7 No holes drilled in isolator enclosure to effect the IP rating of the isolator

  Yes

  No

  N/A

• 1.8 Suitable cable gland used & checked for tightness.

  Yes

  No

  N/A

• 1.9 When isolator is installed externally, all gland entries will be only from the bottom so as to prevent water ingress.

  Yes

  No

  N/A

• 2.0 All connected cable cores checked for tightness & without any copper strands showing.

  Yes

  No

  N/A

• 2.1 Verify that the earth cable conduct is connected straight through the isolator.

  Yes

  No

  N/A

• 2.2 Check functionally of the isolator ON/OFF.

  Yes

  No

  N/A

• 2.3 Check isolator is labelled.

  Yes

  No

  N/A

• 2.4 Check that all connected cables are tested & recorded on a separate test sheet.

  Yes

  No

  N/A

• 2.5 Does the isolator need to be locked off until connected equipment is commissioned.

  Yes

  No

  N/A
