Site Installation Report - duplicate

• Document No. WT/002(S.I.R.)

• Site Inspection Name & Address

• Client

• Report Date

  Date

• Carried out by

In Build Site Quality Check List

• 1). Have actions been completed from last visit?

  Yes

  No

  N/A

• Type of installation:-

  Select Domestic Commercial Industrial

  • Domestic
  • Commercial
  • Industrial

• Wiring types used:-

  Select PVC/PVC PVC/LSF Singles FP200 Other

  • PVC/PVC
  • PVC/LSF Singles
  • FP200
  • Other

• If wiring type is 'Other' please list

Containment:

• Correctly installed

  Yes

  No

  N/A

• Adequate for installation?

  Yes

  No

  N/A

• Lids, lock rings etc. Ok?

  Yes

  No

  N/A

• Sharp edges/extra added protection?

  Yes

  No

  N/A

• All swarm and debris removed?

  Yes

  No

  N/A

• Fire rated/metal cable ties used on cable ties?

  Yes

  No

  N/A

• Fire Stop?

  Yes

  No

  N/A

• Bonded as necessary?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Back boxes:

• Correct type used?

  Yes

  No

  N/A

• Fixings adequate (level)?

  Yes

  No

  N/A

• Installed in permitted zone?

  Yes

  No

  N/A

• Cable entry hole(s) protected?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Cabling:

• Correct cable used for the installation?

  Yes

  No

  N/A

• Cable support correct?

  Yes

  No

  N/A

• Correct cable segregation?

  Yes

  No

  N/A

• Cable routing?

  Yes

  No

  N/A

• Mechanical protection installed as required?

  Yes

  No

  N/A

• Fire rated cable supports?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Earthing & Bonding:

• Correctly installed?

  Yes

  No

  N/A

• Cabling adequately sized?

  Yes

  No

  N/A

• Cables correctly labelled?

  Yes

  No

  N/A

• M.E.T. / Test link present?

  Yes

  No

  N/A

• Supplementary Bonding?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Distrbution Boards/Panels:

• Adequate for installation?

  Yes

  No

  N/A

• Fixings adequate?

  Yes

  No

  N/A

• Location adequate?

  Yes

  No

  N/A

• Accessibility?

  Yes

  No

  N/A

• Cable entry glanced/hole(s) protected?

  Yes

  No

  N/A

• Temporary distribution board chart?

  Yes

  No

  N/A

• CPD's correct and RCD afforded?

  Yes

  No

  N/A

• Conductors sleeved & colour identified?

  Yes

  No

  N/A

• Conductor circuit identification in place?

  Yes

  No

  N/A

• Required distribution board labelling in place?

  Yes

  No

  N/A

• Polarity and Phase sequencing correct?

  Yes

  No

  N/A

• Safe isolation in place?

  Yes

  No

  N/A

• Completed circuit chart present?

  Yes

  No

  N/A

• Correctly terminated/No copper visible?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Face Plates:

• Secured and level?

  Yes

  No

  N/A

• Fixing adequate?

  Yes

  No

  N/A

• Correct type used?

  Yes

  No

  N/A

• Wires sleeved where applicable?

  Yes

  No

  N/A

• Correctly terminated/no copper visible at terminals?

  Yes

  No

  N/A

• Wires terminated in correct terminals?

  Yes

  No

  N/A

• Labelled where applicable?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Lighting:

• Lamps fitted and checked?

  Yes

  No

  N/A

• Diffusers fitted & checked?

  Yes

  No

  N/A

• Correct switching locations?

  Yes

  No

  N/A

• Downlights inspected?

  Yes

  No

  N/A

• Adequate fireguard of downlights?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Emergency & Exit lighting:

• Lamps fitted and checked?

  Yes

  No

  N/A

• Diffusers fitted and checked?

  Yes

  No

  N/A

• Installed in appropriate locations?

  Yes

  No

  N/A

• Testing facilities installed and labelled?

  Yes

  No

  N/A

• Identification numbers on luminaries?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Fire Alarm:

• Fixings adequate on cable runs?

  Yes

  No

  N/A

• Fire alarms interlinked?

  Yes

  No

  N/A

• Domestic: alarms installed due to Part P?

  Yes

  No

  N/A

• Add 'Good Example' photo(s)

  Media

Site Health & Safety Folder:

• Relevant sections are present and filled in?

  Yes

  No

  N/A

• Installation test sheets present and up to date?

  Yes

  No

  N/A

• Safe isolation - 'Request for isolations' completed?

  Yes

  No

  N/A

• Safe isolation - 'Request for power' completed?

  Yes

  No

  N/A

• Any other Comments:

• Inspector Signature:

  Sign

• Contract Managers Signature:

  Sign

• Site Managers Signature:

  Sign
