Underground Cabling Quality Audit

2m to 4m coil in nearest chamber to pole. Take photos to demonstrate.

Correctly dressed cable in pit with correct bend radius, cable using full length of chamber, no tight bends. Take photos to demonstrate

Cable correctly secured using flat bar, or joint support kit 1A. Take photos to demonstrate

A frame with crossed cable ties. Take photos to demonstrate

Flat bar or joint support kit 1A fitted to bearers with crossed cable ties. Take photos to demonstrate

Cable ties cut flush.Take photos to demonstrate

Gel wraps and connectors fitted correctly. Take photos to demonstrate

25mm and 16mm sub-duct supported. Take photos to demonstrate

All sub-duct and cable labelled. Take photos to demonstrate

Corning CBT cable yellow tape 300mm apart. Take photos to demonstrate

All cable ties cut ends removed from chamber. Take photos to demonstrate

Corning CBTs minimum 150mm clearance. Take photos to demonstrate

Mobra fitted tight with no movement. Take photos to demonstrate

Penny washers used on mobra arm. Take photos to demonstrate

Are the CBTs labelled? Take photos to demonstrate

Is there enough slack on the CBT and joint cable when the mobra arm is lifted? Take photos to demonstrate

Are the fibre joints labelled? Take photos to demonstrate
