Title Page

  • Conducted on

  • Audit completed by

1st Floor

1st floor

  • Emergency light (top of stairs)

  • Panel 1 (Located on the back wall)

  • Rotary switch (red/yellow isolate)

  • Rotary valve switch (red/yellow solator)

  • Double plug socket

  • Fly unit power switch

  • Emergency stop (red/yellow) and black socket

  • Blue valve switch (by emergency stop)

  • Grey junction box

Panel 2 (Located on the back wall)

  • Eyewash box

  • Grey junction box with black reset button

  • Grey junction box

  • Cone mill isolator switch and grey box

  • Sieve switch and grey box

  • Spare isolator switch and grey box

  • Toshiba A/C control panel

  • Emergency stop (red/yellow) and black socket

Panel 3 (Located on the back wall)

  • Rotary switch (red/yellow isolate)

  • Rotary valve switch (red/yellow solator)

  • Double plug socket

  • Red/yellow emergency stop and black socket

  • Blue valve switch (by emergency stop)

  • Grey junction box

Rip Tip Area

  • Waste bin

  • Fire extinguisher x 2

  • Sack Tip Hopper Vortex Valves junction box with cables

  • Pressure gauge below junction box

  • "WAM Fikentr d Time' Panel & Grey Cable

  • RH Air Pressure Regulator and cable (behind junction box)

  • LH Air Pressure Regulator and cable (behind junction box)

  • Green & Yellow earth cable to sleeve

  • Clear dust extraction pipe

  • Blue handle on dust extraction pipe

  • Black knob on dust extraction pipe

  • Red knob on both sides of Rip & Tip

  • Blue handles on sieve

  • Black knobs on magnet housing (below sieve)

  • Blue rubber cover (below magnet)

  • Blue/Clear rubber discharge pipe cover

  • Black "Schmand" box with gray cables on magnet housing

  • Blue rubber discharge pipe cover (cone mill)

  • Blue cleaning equipment or shadow board

  • Mixer Control Panel (2 white LEO's 1 E-stop, Blue reset button LED Display)

  • Twin plug socket (Battery charging area)

  • Bailer Controls (Black switch, 1 red button, 1 green button, 1 lever)

  • Handle on bailer

  • Power cable and socket for bailer

  • Emergency Lighting

  • POET truck - ensure all parts are present and intact

Mixer 2 Area

  • "KEK DOOR SWITCHES" Junction box and cables on mixer

  • "Mixer 2 Rotary Sieve / Rotary Valve" Junction Box and cables

  • Yellow Cap (end of rotary valve)

  • Red End Cap on Rotary Valve

  • Round black knob side of mixer

  • Black star knob on rotary valve

  • Orange Cable End (behind Black "Star" Knob)

  • Blue/grey circular valve

Packing head sieve

  • Blue handles on the sieve

  • Black star handle and orange connector

  • Red end cap (to the right of the black star handle)

  • Clear collar going into the sieve

  • Black junction box, black cables and yellow & green cable

  • Blue pipework, black connectors and white junction box

  • Clear collar underneath the sieve housing
