Inspection Information

  • Project Name:

  • Project Location:

  • Permit #:

  • Date of Inspection:

Hydrostatic Test

  • Wet sprinkler system must hold minimum of 200 psi for 2 hours.

  • Confirm underground fire line has been finaled:

  • Start Pressure (psi):

  • Start Time:

  • Pressure pump to be disconnected after wet sprinkler system is pressurized to 200 psi.

  • End Pressure (psi):

  • End Time:

  • Pressure relieved and gauge returns to zero psi:

Hydrostatic Test Status

  • Hydrostatic Test Status:

  • Date of Completion:

Visual Inspection

Piping and Hangers

  • Proper type of piping:

  • Piping layout and size:

  • Branch lines have one hanger per section of pipe:

  • Mains and cross-mains have hanger between branch lines and at ends:

  • Maximum distance between end sprinkler and hanger:<br> - 48" for 1-1/4" piping<br> - 60" for 1-1/2" or greater piping

  • Risers have supports at lowest level, alternate level, and at the top:

  • Hangers are not within 3" of upright sprinkler heads:

Sprinklers

  • Type, temperature, and spacing of sprinklers match plans:

  • Heads are a minimum of 4 inches from wall:

  • Heads are spaced a minimum of 6 feet on center:

  • Pendent heads are 1 to 12 inches below ceiling:<br>Sidewall heads are 4 to 6 inches from ceiling:

  • Are Early Suppression Fast Response (ESFR) heads used?

  • ESFR upright deflectors are minimum of 7 inches above top of pipe:

  • ESFR heads are at least 1 foot away (horizontally) from bottom of joist or truss:

  • ESFR heads are at least 3 feet above the top of the level of storage:

Riser

  • Main drain sized as shown on plans:

  • Main drain piped outside or to inside floor drain:

  • Back flow prevention device is correct size and type:

  • Back flow prevention device has correct direction of flow:

Fire Department Connection

  • 5 inch Storz connection with a 30 degree downturn provided:

  • Check valve behind each connection:

  • Drip valve provided for each connection:

Visual Inspection Status

  • Visual Inspection Status:

  • Date of Completion:

Final Acceptance Test

Sprinkler System

  • Verify sprinkler placement matches approved plans:

  • Verify sprinkler type and temperature match approved plans:

  • Verify sprinkler heads are clear from obstructions:

  • Verify sprinkler heads are free from paint, coverings, etc:

  • Verify sprinkler escutcheons are installed where required:

  • Verify ceiling pockets / skylights are properly protected:

  • Remote inspector's test connection labeled and accessible:

  • All low-point drains are clearly labeled and accessible:

  • Sign at each control valve indicating the portion of the building which it serves:

Riser Room

  • Hydraulic name plate is attached to the riser:

  • General information sign posted with the following information:

  • Name and location

  • Presence of high-pile / rack storage

  • Max storage height planned

  • Aisle width planned

  • Commodity classification

  • Encapsulation status

  • Presence of solid shelving

  • Flow test data

  • Presence of flammable / combustible liquids

  • Presence of Haz-Mat

  • Presence of other special storage

  • Location of auxiliary and low-point drains

  • Main drain flow test results

  • Location of dry / antifreeze systems

  • Number of sprinkler heads in the system:

  • Minimum of 6 spare sprinkler heads provided:

  • Minimum of 12 spare sprinkler heads provided:

  • Minimum of 24 spare sprinkler heads provided:

  • Replacement wrench(es) provided:

  • Multiple risers?

  • Each riser numbered and consistent with alarm addressing:

  • Main drain labeled:

  • Riser room has label and Knox Box -OR- exterior OS&Y / PIV provided:

  • Riser room has hard wired heat, light, and emergency lighting:

Fire Department Connection

  • Connections are 18 to 48 inches above finished grade with Knox Caps:

  • 5 foot pathway leading to FDC:

  • FDC clearly visible and facing fire lane:

  • Sign indicating which system the FDC serves and which address(es) it serves:

System Testing

  • Pressure switch activates within 45 to 90 seconds:

  • Main drain test completed and recorded:

  • Verify DCVA forward flow tested and performance tested:

  • Aboveground contractor material and test certificate provided:

Final Acceptance Test Status

  • Final Acceptance Test Status:

  • Date of Completion:

Inspection Status

Additional Comments

  • Comments:

Inspection Summary

  • Hydrostatic Test Inspection:

  • Visual Inspection:

  • Final Inspection:

Inspection Status

  • On-site Inspector:

  • Inspection Status:

  • Next Inspection:

  • Date Finaled:

Acknowledgement of Receipt

Acknowledgement of Receipt

  • Persons who shall violate a provision of this code or shall fail to comply with any requirements thereof or who shall erect, install, alter, repair, or do work in violation of the approved construction documents or directive of the fire code official, or of a permit or certification used under provisions of this code, shall be guilty of a Class C Misdemeanor, punishable by a fine of not more than $2,000.00 dollars, or by imprisonment not to exceed 180 days, or both such fine and imprisonment. Each day that a violation continues after due notice has been served shall be deemed a separate offense.

    By signing below, I acknowledge that I have received, reviewed, and understand the code violations listed in this inspection report. I also agree to correct these code violations in the amount of time specified, in this document, by the Fire Marshal of the City of Rockwall.

  • Email Address:

  • Signature:
