Construction Compliance Certificate Assessment

• Subdivision & Stage or Address

• DA number

• Prepared by

  Select Nathan McBriarty Phil Thompson Bernie Boland Ron Brear Joel Harris Luke Preston Bryce Short

  • Nathan McBriarty
  • Phil Thompson
  • Bernie Boland
  • Ron Brear
  • Joel Harris
  • Luke Preston
  • Bryce Short

APPLICATION & PROPERTY LOCATION DETAILS

• Development Application No.

• Development Proposal

• Lot

• DP

• Address

• Assessment Officer

  Select Nathan McBriarty Phil Thompson Bernie Boland Ron Brear Joel Harris Luke Preston Bryce Short

  • Nathan McBriarty
  • Phil Thompson
  • Bernie Boland
  • Ron Brear
  • Joel Harris
  • Luke Preston
  • Bryce Short

• Start Date

  Date

• Signing Officer

  Select Nathan McBriarty Phil Thompson Bernie Boland Ron Brear Joel Harris Luke Preston Bryce Short

  • Nathan McBriarty
  • Phil Thompson
  • Bernie Boland
  • Ron Brear
  • Joel Harris
  • Luke Preston
  • Bryce Short

DA APPROVAL

• Date of DA approval

• Select date

  Date

• Are there any S96 amendments?

  Yes

  No

  N/A

• Current Part

  Select Part 1 Part 2 Part 3 Part 4 Part 5 Part 6 Part 7 Part 8 Part 9 Part 10 Part 11 Part 12 Part 13 Part 14 Part 15 Part 16 Part 17 Part 18

  • Part 1
  • Part 2
  • Part 3
  • Part 4
  • Part 5
  • Part 6
  • Part 7
  • Part 8
  • Part 9
  • Part 10
  • Part 11
  • Part 12
  • Part 13
  • Part 14
  • Part 15
  • Part 16
  • Part 17
  • Part 18

CONSTRUCTION CERTIFICATE PLANS

• Construction Certificate Plans Prepared by?

• Date approved

  Date

• Insert PDF Plans here

  Media

COMMENCEMENT OF WORKS ON SITE

• 1. Site Establishment

• Pre-Construction Meeting

  Off

  On

• Inspection/Test results to be submitted prior to approval to proceed to next activity

• Nominated Site Supervisor for the Project

  Yes

  No

  N/A

• List of all Sources and Suppliers of Materials submitted and approved by Council?

  Yes

  No

  N/A

• Written evidence that the Contractor has current Public Liability Insurance and Workers Compensation Insurance with Council nominated as in interested party submitted to Council?

  Yes

  No

  N/A

• Date inspected

  Date

• 2. Commencement of Earthworks

• Inspection/Test results to be submitted prior to approval to proceed to next activity

• Soil and Water Management Measures installed and to satisfaction?

  Yes

  No

  N/A

• Select date

  Date

EARTHWORKS

• 3. Placing of Fill on Roads and/or Lots

• Inspection/Test results to be submitted prior to approval to proceed to next activity

• Stripped areas inspected & to satisfaction?

  Yes

  No

  N/A

• Date inspected

  Date

ROAD CONSTRUCTION

• 4. Road Subgrade

• Subgrade replacement - Granular material max 50mm aggregate

Road Subgrade Inspection

• Road & Chainage details

• Compaction Density Geotechnical test result submitted?<br>100% standard 95% modified

  Yes

  No

  N/A

• Proof roll - no sign of deflections?<br>Single axle loaded water truck or similar (min 8 tonne loaded over the rear axle)

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Material that has become degraded, segregated or otherwise reduced in quality by reworking shall be rejected. Clayey and soft areas to rejected. Rejected material shall be removed, disposed of and replaced with fresh material approved by Council. Subgrade replacement - Granular material max 50mm aggregate

• Date inspected

  Date

• 5. Road Subbase

• DGS 20 - 20mm nominal sized densely graded subbase
  DGS 40 - 40mm nominal sized densely graded subbase

Road Subbase Inspection

• Road & Chainage details

• Was road subgrade satisfactory/approved at this location?

  Yes

  No

  N/A

• Has a road drainage infrastructure been installed at this location?

  Yes

  No

  N/A

• Have subbase material source and type details been submitted/approved by Council?

  Yes

  No

  N/A

• Compaction Density Geotechnical test result submitted?<br>100% standard 95% modified

  Yes

  No

  N/A

• Proof roll - no sign of deflections?<br>Single axle loaded water truck or similar (min 8 tonne loaded over the rear axle)

  Yes

  No

  N/A

• Service conduit plan submitted?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Material that has become degraded, segregated or otherwise reduced in quality by reworking shall be rejected. Rejected material shall be removed, disposed of and replaced with fresh material approved by Council.

• Date inspected

  Date

• 6. Kerb & Gutter

• Concrete to be minimum 20 MPA

Kerb & Gutter Inspection

• Road & Chainage Details

• Has the Subbase been approved at this location?

  Yes

  No

  N/A

• Does Subbase extend 150mm behind kerb?

  Yes

  No

  N/A

• Are kerb adapters in place and not located at contraction or expansion joints?

  Yes

  No

  N/A

• Is there adequate fall to inlet pits?<br>min 0.5% grade

  Yes

  No

  N/A

• Are contraction joints located every 3m and expansion joints at intervals not exceeding 15m?

  Yes

  No

  N/A

• Are services conduit locations adequately stamped and marked on the kerb?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

• 7. Base

• DGB 20 - 20mm nominal sized densely graded base

Base Inspection

• Road & Chainage Details

• Has the Subbase been approved?

  Yes

  No

  N/A

• Have base material source and type details been submitted/approved by Council?

  Yes

  No

  N/A

• Proof roll - no sign of deflections?<br>Single axle loaded water truck or similar (min 8 tonne loaded over the rear axle)

  Yes

  No

  N/A

• Compaction Density Geotechnical Test result submitted?<br>98% Modified

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Material that has become degraded, segregated or otherwise reduced in quality by reworking shall be rejected. Rejected material shall be removed, disposed of and replaced with fresh material approved by Council.

• Date inspected

  Date

• 8. Seal - Wearing Surface

• Hotmix 2x 20mm layers - 2nd layer after 80% of houses built or 12 months whichever comes first
  or 1x 40mm layer. Check approved consent.

Final layer Inspection

• Road & Chainage Details

• Has the base at this location been approved?

  Yes

  No

  N/A

• CCTV footage of road drainage pipeline satisfactory?

  Yes

  No

  N/A

• Benkelman Beam Test submitted?<br>No deflection > 1mm

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

DRAINAGE

• 9. Subsoil Drainage

• Bedding - 7mm or 10mm single sized aggregate filter material 300mm of depth
  Note: in wet areas single coarse 10mm aggregate used to drain easily

Subsoil line Inspection

• Subsoil Drainage Line Details

• Subsoil drainage plan submitted satisfactory?

  Yes

  No

  N/A

• Subsoil drainage located on high side of all roads?

  Yes

  No

  N/A

• Excavation in accordance with plan?

  Yes

  No

  N/A

• Bedding and subsoil drainage pipe in trench satisfactory?

  Yes

  No

  N/A

• Is the pipe enclosed in a seamless tubular geotextile filter fabric?

  Yes

  No

  N/A

• Flush points provided?<br>At max intervals of 80m

  Yes

  No

  N/A

• Backfill trench to subgrade level?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

• 10. Stormwater Pipelines

• Bedding - 7mm Quarry blend, 100mm thick, compaction 70
  Note: in wet areas single coarse 10mm aggregate used to drain easily

Pipeline Inspection

• Drainage Line Details

• Are pipelines of a satisfactory concrete cure date?<br>Pipe 450mm and less date of manufacture > 14 days<br>Pipe greater 450mm and less date of manufacture > 7 days

  Yes

  No

  N/A

• Pipeline trench widths comply?

  Yes

  No

  N/A

• Location of pipeline consistent with approved plans?

  Yes

  No

  N/A

• Adequate trench wall clearance from pipe to wall?<br>minimum 150mm

  Yes

  No

  N/A

• No poor joints, damage, unsealed lifting holes?

  Yes

  No

  N/A

• Grades consistent with approved plans?

  Yes

  No

  N/A

• Compaction Density test results for bedding, haunch, side and overlay zones satisfactory?<br>Compacted to a density index minimum 70%.

  Yes

  No

  N/A

• Backfill to finished Subgrade level?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

• 10. Kerb & Gutter Drainage Inlet Pits

• Precast pits - no honeycomb present & manufacture approved by Council

K&G inlet pit Inspection

• K&G Drainage Pit location details

• Location of pits consistent with approved plans?

  Yes

  No

  N/A

• No poor joints, damage, unsealed lifting holes?

  Yes

  No

  N/A

• Are floors rendered and self flushing?

  Yes

  No

  N/A

• Are subsurface drains present?<br>100mm diameter pipeline enclosed in seamless geotextile filter fabric extending 3m from the discharge end of pipes

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

INTER-ALLOTMENT SYSTEMS & DRAINAGE STRUCTURES

• 14. Inter-allotment system
Inter-allotment Inspection

• Inter-allotment system location details

• Pits & pipes location in accordance with approved plans?

  Yes

  No

  N/A

• Are all pits rendered and self flushing?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

• 14. Place Concrete for Pits, Headwalls or Culvert Base Slabs
Drainage Structure Inspection

• Drainage Structure Details

• Reinforcing in accordance with approved plans?

  Yes

  No

  N/A

• Manufactures certification for precast products submitted & approved?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Date inspected

  Date

MISCELLANEOUS ADHOC INSPECTION

• 15. Miscellaneous Inspection
Miscellaneous Inspection

• Inspection notes

• Add media

  Media

• Satisfactory?

  Yes

  No

  N/A

• Enter corrective action to be taken

• Date inspected

  Date

FINAL INSPECTION

• 16. Final Construction Inspections

• Construction complies with approved plans?

  Yes

  No

  N/A

• Shape and Grade in accordance with approved plans?

  Yes

  No

  N/A

• CCTV of all stormwater pipelines satisfactory?

  Yes

  No

  N/A

• Benkelman Beam testing submitted and satisfactory?<br>Max deflection: 10^4 ESA = 2mm, 10^ 5 ESA = 1.6mm, 10^6 ESA = 1.2mm, <br>Reference: Guide to Pavement Technology Part 5: Pavement Evaluation and Treatment Design, Figure 6.5

  Yes

  No

  N/A

• Are all roads and kerb & gutter in satisfactory condition?

  Yes

  No

  N/A

• All areas levelled and stabilised?

  Yes

  No

  N/A

• All drainage infrastructure in satisfactory condition?

  Yes

  No

  N/A

• Council Infrastructure left in satisfactory condition?

  Yes

  No

  N/A

• Inter-allotment system checked to see if pipeline between each pit has not been crushed or moved?

  Yes

  No

  N/A

• Satisfactory?

  Yes

  No

  N/A

• Please issue construction compliance certificate.

• Date inspection

  Date

Signature

• Add signature

  Sign

• Date completed

  Date
