PUWER Assessment (including mobile)

• Assessment Number (Zone-P-Sequence Number)

• Site and Department/Area

• Conducted by

  Sign

• Conducted on

  Date

• Description of equipment

• Equipment Serial Number (or Asset Number)

• Photograph of equipment

  Media

• Persons using equipment

• Frequency of use (eg hourly, daily, weekly etc)

4.1 Construction

• Guidance: All work equipment is to be constructed or adapted so as to be suitable for the purpose for which it is being used or provided, and every employer should ensure that all work equipment is used only for operations for which, and under conditions for which, it is suitable. Consideration must be given to initial integrity, the place where it will be used, and the purpose for which it will be used.


• ACOP: When selecting work equipment, employers should take into account ergonomic risks so the operators do not have to exert undue force or stretch beyond normal strength or physical reach

• Is the work equipment constructed and adapted for the purpose for which it is used?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 4 (suitability of work equipment)

• Responsible

4.2 Installation

• Guidance: Employer must ensure that equipment is suitable for the process and conditions of use

• ACOP: Work equipment should be installed, located and used in such a way as to reduce risks to users of the work equipment and other workers. Consideration needs to be given to ensure that there is sufficient space between the moving parts of work equipment and fixed or moving parts in its environment, and that all forms of energy and substances used or produced can be supplied and/or removed in a safe manner

• Has the work equipment been selected taking into account the working conditions, including existing and any additional risks?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 4 (suitability of work equipment)

• Responsible

4.3 Use

• Is Work equipment only used for the operations and under the conditions for which it is suitable?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 4 (suitability of work equipment)

• Responsible

5.1 Maintenance activities

• Guidance: All work equipment should be maintained in an efficient state, in efficient working order and in good repair. Maintenance may include routine maintenance based on recommendations of the equipment manufacturer and planned preventive maintenance (where inadequate maintenance could cause equipment, safeguard, or other protection failure in a dangerous way). Frequency of maintenance activities should take into account:

  a) intensity of use - frequency and maximum working limits;
  b) operating environment - eg outdoors
  c) variety of operations - is the equipment performing the same task or does this change?
  d) risks from malfunction or failure

• Is work equipment maintained in an efficient state, efficient working order, and in good repair?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 5 (Maintenance of work equipment)

• Responsible

5.2 Maintenance Records

• Guidance: The maintenance of work equipment should be properly managed. i.e. planned preventative maintenance, condition based maintenance, or breakdown based maintenance.

• If the machinery has a maintenance log, is it kept up to date?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 5 (Maintenance of work equipment)

• Responsible

• Guidance: Equipment that should receive an inspection will include:

  a) Horizontal injection moulding machine
  b) Paper cutting guillotines
  c) Diecasting machines
  d) Shell moulding machines
  e) Complex automated equipment
  f) Integrated production lines

  Your risk assessment should identify any other work equipment where deterioration could cause a significant risk and which should therefore be inspected. Inspections should include visual checks, functional checks and testing, completed by competent person and recorded.

6.1 Initial inspection

• Where safety of equipment depends on installation conditions, has a competent person inspected it after installation, before putting it into service?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 6 (Inspection)

• Responsible

6.2 Inspection for deterioration

• Where equipment could deteriorate, which could result in dangerous situations, has a schedule of inspections been planned?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 6 (Inspection)

• Responsible

7.1 Control of specific risks

• ACOP: Risks must be controlled by:

  a) elimination of the risks or, if not possible,
  b) taking hardware (physical) measures to control the risk such as the provision of guards:

  But if the risk cannot be adequately controlled:

  c) Taking appropriate measures to deal with residual risk such as following a safe system of work and the provision of information, instruction and training.

• Is work equipment free from specific risks to health and safety?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 7 (Specific risks)

• Responsible

7.2 Control of maintenance, repair and modification risks

• ACOP: A designated and adequately trained person for maintenance repair and modification should have received proper instruction, information and training for such work.

• Is a designated and adequately trained person available to carry out repairs, modifications or other similar work on the equipment?

  Yes

  No

  N/A

Actions:

• Actions required

Action:

• Action from Regulation 7 (Specific risks)

• Responsible

• Guidance: Information can be in writing or verbal where this is considered to be sufficient. Written instructions refer primarily to the information provided by manufacturers or suppliers, such as instruction sheets or manuals, instruction placards, warning labels and training manuals.

• ACOP: Any information and written instructions you provide should be readily comprehensible and cover:
  a) all health and safety aspects arising from the use of work equipment
  b) any limitations on these uses
  c) any foreseeable difficulties that could arise
  d) the methods to deal with them

8.1 Information availability

• Do all equipment operators have available; adequate health and safety information and instructions for use of work equipment?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 8 (Information and Instruction)

• Responsible

8.2 Information content

• Does information and instruction provided to the users include: <br>a) conditions under which, and methods by, equipment may be used<br>b) foreseeable abnormal conditions actions to be taken?<br>c) any conclusions drawn from experience in using the equipment?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 8 (Information and Instruction)

• Responsible

• Guidance: All persons who use, manage, or supervise the use of work equipment should have received adequate training for purposes of health and safety, including training in the use of the work equipment, any risks involved and precautions to be taken. There is a clear overlap with regard to the training requirements of the management of health and safety at work regulations 1992.

• ACOP: Specific training will be required for certain types of work equipment such as self-propelled work equipment, power presses, woodworking machines and chainsaws.

9.1 Training

• Have all persons who use, manage, or supervise the use of work equipment been adequately trained?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 9 (Training)

• Responsible

• Guidance: You should check that any work equipment provided for use after 31 December 1992 bears a CE mark and has an EC declaration of conformity.

  Refer to schedule 1 of the ACOP/guidance for a list of the relevant statutory instruments. The work equipment should be provided with suitable operating instructions, and information should be available about residual hazards such as noise and vibration. You must check the equipment for obvious hazards that have not been adequately or appropriately dealt with by the equipment manufacturer or supplier.

10.1 Community Requirements

• Has the work equipment been designed and constructed in compliance with any essential requirements?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 10 (community requirements)

• Responsible

11.1 Preventing access

• Guidance: The regulations provide a hierarchy of guarding of dangerous part of machinery, i.e. any piece of work equipment which could cause injury. Measures should be taken to prevent access to any dangerous part of machinery, or to stop the movement of any dangerous part of machinery, before any part of the person enters the danger zone.

• Are effective measures in place to prevent access to dangerous parts of machinery? (Or to any rotating barstock)

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 11 (dangerous parts of machinery)

• Responsible

11.2 Measures used

• Guidance: Your risk assessment should identify the hazards presented by machinery and evaluate the risks. The objective is to prevent contact with any dangerous part of the machine using measures descended from the top of the scale from (a) to (d) below

• Do the measures required to be taken consist of one of the following?<br>(Please comment on which is used)<br><br>(a) The provision of fixed guards closing every dangerous part? <br>(b) Where (a) is not practical, then the provision of other guards or protection devices? <br>(c) Where b) not practical, then the provision of jigs, holders, push sticks or other similar protection devices used in conjunction with the machinery? <br>(d) Where (c) is not practical, then the provision of information, instruction, training and supervision?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 11 (dangerous parts of machinery)

• Responsible

• Are guards/protection devices suitable for purpose, of sound construction, adequate strength, and maintained in working order, and in good repair?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 11 (dangerous parts of machinery)

• Responsible

• Are they such that they did not give rise to any increased risk to health and safety and cannot be easily bypass or disabled?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 11 (dangerous parts of machinery)

• Responsible

• Are they situated at sufficient distance from the danger zone and do not unduly restrict the view of the operating cycle where such a view is necessary?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 11 (dangerous parts of machinery)

• Responsible

• Are the guards constructed or adapted so that they allow for maintenance without having to dismantle the guard or protection device?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 11 (dangerous parts of machinery)

• Responsible

12.1 Protection against specific hazards

• Guidance: Employers should prevent articles or substances falling or being injected from work equipment, rupture or disintegration of parts or work equipment, work equipment catching fire or overheating, the unintended or premature discharge of any article, gas, dust, liquid, vapour or other substance from work equipment, or the unintended or premature explosion of the work equipment.

  Where this is not reasonably practicable then such matters should be adequately controlled. Your risk assessment should identify if any of these hazards are relevant and the actions that you need to take.

• Is work equipment protected against specific hazards e.g. falling articles, disintegration, ejection, overheating, explosion etc?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 12 (Protection against specific hazards)

• Responsible

12.2 Control measures

• Guidance: PPE may be appropriate where a risk remains that cannot be eliminated. Training etc will have an important role to play.

• Are control measures by means other than provision of PPE, or information, instruction, training or supervision (so far as is reasonably practicable)?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 12 (Protection against specific hazards)

• Responsible

13.1 High, or very low temperatures

• Guidance: You should ensure that work equipment, parts of the equipment and articles or substances produced, used or stored in work equipment are protected so as to prevent injury to any person By burn, scald or sear.

  The risk from contact with hot or cold services should be reduced by engineering methods, i.e. reduction or increase in surface temperatures, insulation, shielding, barricading and guarding.

  While engineering measures should always be applied, Where appropriate, alternative or complimentary forms of protection might also be necessary e.g. PPE, warning signs instructions, training, supervision etc

• Are work equipment surfaces, and any articles or substances produced, protected against high or very low temperatures?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 13 (High or very low temperatures)

• Responsible

• Guidance: Where appropriate, work equipment should be provided with one or more controls for starting the work equipment and for controlling any change in speed, pressure or other operating conditions of work equipment, where such change may result in increased risk.

  Controls should be designed and positioned so as to prevent inadvertent or accidental operation.

  It should only be possible to stop equipment by using appropriate controls. You should not normally be able to restart any equipment simply by resetting a protection device e.g. interlock - operation of the start control should also be required. The control must not be capable of starting itself due to effects of gravity, failure of a spring mechanism etc

14.1 Controls for starting or restarting work equipment

• Are adequate controls provided for starting the work equipment? (Including restarting after a stoppage for any reason)

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 14 (controls for starting or changing operating conditions)

• Responsible

14.2 controls for any change in speed, pressure or other operating conditions

• Are adequate controls provided for controlling any change in speed, pressure or other operating conditions of work equipment, where such conditions, after the change, result in a risks to health and safety which is greater than, or of a different nature from, the risks before the change?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 14 (controls for starting or changing operating conditions)

• Responsible

15.1 Stop Controls

• Guidance: Where appropriate, work equipment should be provided with one or more readily accessible controls to stop the work equipment to a safe condition, in a safe manner. If required for safety, the stop control does not have to be instantaneous.

• Is work equipment provided with one or more readily accessible controls to stop work equipment?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 15 (Stop Controls)

• Responsible

16.1 Emergency stop controls

• Guidance: An emergency stop control should be provided where the other safeguards are not adequate to prevent risk when some irregular event occurs. However, this is not a substitute for necessary safeguarding.

  Where it is appropriate to have one, emergency stops should be provided at every control point and at other appropriate locations around equipment so that action can be taken. Your risk assessment should identify where emergency stops are required. Emergency stops should be easily reached and activated.

• Where appropriate, is work equipment provided with one or more readily accessible emergency stop controls?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 16 (emergency stop controls)

• Responsible

17.1 marking of controls

• Are all controls for work equipment clearly visible and identifiable and appropriately marked where necessary?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 17 (Controls)

• Responsible

17.2 Control positioning

• Are all controls for work equipment in a safe position?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 17 (Controls)

• Responsible

17.3 Control operation

• Guidance: Where controls have to be positioned where people are at some risk, e.g. robot teaching pendant, particular precautions should be used, e.g. hold to run controls, reduced or limited capability of equipment. You may need to employ additional measures if someone could remain inside safeguards at start-up. Any warnings must be ambiguous, easily perceived easily understood.

• Are persons operating such controls able to ensure that there is no other person in place of danger?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 17 (controls)

• Responsible

• Where this is not reasonably practical, are safe systems in place to ensure that persons are not in danger when the equipment is about to start?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 17 (controls)

• Responsible

• If neither of these options are appropriate or reasonably practicable, is there an audible, visible or suitable warning given?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 17 (controls)

• Responsible

18.1 Control Systems

• Guidance: All control systems of work equipment must be safe and operation must not create an increased risk to health or safety. Faults in, or damage to, any part of the control system must not result in additional or increase risk and should lead to "failsafe" condition.

• Are all control systems safe, free from faults or damage and do not impede access to stop controls?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 18 (control systems)

• Responsible

19.1 Isolation from sources of energy

• Guidance: If work on isolated equipment is done by more than one person, locking devices with multiple locks and keys might be necessary. In some cases sources of energy may need to be maintained when equipment is stopped so measures will need to be taken to eliminate risks before attempts are made to isolate.

• Is work equipment provided with suitable, clearly identifiable and readily accessible means of isolating it from its source of energy?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 19 (Isolation from sources of energy)

• Responsible

20.1 Stability

• Guidance: All work equipment and parts of work equipment should be stabilised by clamping, or otherwise secured for the purposes of health and safety.

  Most machines used in a fixed position should be bolted or otherwise fastened down so that they do not move or rock during use.

  Mobile work equipment must always be used within the limits of its stability.

• Is the work equipment stable?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 20 (Stability)

• Responsible

21.1 Lighting

• Guidance: Suitable and sufficient lighting, which takes account of the operations need to be carried out, should be provided at any place where a person uses work equipment.

  If ambient lighting provided in the workplace is suitable and sufficient for the tasks involved then special lighting need not be provided; but if the task involved the perception of detail then additional lighting would need to be provided to comply with the regulations.

  Additional lighting should also be provided in areas not covered by general lighting when other work activities, such as maintenance or repairs, are carried out.

  Permanent lighting should always be considered where access is foreseeable on intermittent but regular basis.

• Is suitable and sufficient lighting provided to the work equipment?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 21 (Lighting)

• Responsible

22.1 Shutting down for maintenance

• Guidance: Where reasonably practicable, steps should be taken to ensure that work equipment is constructed or adapted so that it can be maintained whilst shut down. You need to review the measures provided by the manufacturer.

  Also remember that if faultfinding may be required where the equipment has to be live your answer must be "NO"

• Guidance: If there are no risks even when the equipment is not completely shut down, then you will obviously need to take no action. Remember to consider contact with live electrical parts in the Control Panel.

• Guidance: Live conductors within panels may need additional shrouding if they are not "finger proof". The risk will depend on the current and voltage, degree of exposed conductor, frequency of access, foreseeability of contact etc.

  If the equipment has to be running or working during maintenance operation, and this presents risks, then measures should be taken to enable the operation of the equipment to continue in a way that reduces risk, e.g. temporary guards, limited movement controls, crawl speed operated by hold to run controls etc.

  Other measures that can be taken to protect against residual risk may include wearing PPE and provision of instruction and supervision.

• Can the work equipment always be shut down for maintenance?

  Yes

  No

  N/A

• If "No" can appropriate measures be taken to protect persons during maintenance?

  Yes

  No

  N/A

• If "No", then can maintenance be carried out without there being any risks to health and safety?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 22 - Maintenance Operations

• Responsible

23.1 Health and safety markings clarity

• Guidance: All the equipment should be marked in a clearly visible manner with any marking appropriate for reasons of health and safety.

  Examples might include clear marking of stop and start controls, including isolators, the maximum rotation speed abrasive wheels, maximum safe working loads of lifting equipment in accessories, marking of compressed gas cylinders, colour coding or marking of pipelines and vessels etc.

  Work equipment should incorporate any appropriate warnings or warning devices. Such warnings should be unambiguous, easily perceived and easily understood (e.g. positive instructions, prohibitions, and restrictions).


• Is work equipment clearly and visibly marked and labelled for the purposes of health and safety?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 23 - Markings

• Responsible

23.2 Marking location

• Guidance: Warnings can be permanent printed warnings, which may be attached to, or incorporated into, equipment or positioned close to it. Additionally, there may be also need for portable warnings which are required to be posted during temporary operations.

  Where words can be augmented by, or replaced by, appropriate graphical signs, they should be in accordance with the health and safety (safety signs and signals) regulations 1996.

  Warning devices can be portable e.g. reversing alarm on vehicle, or visible. They may indicate imminent danger, development of a fault condition, or the continued presence of a potential hazard. Examples include "not to be operated by persons under 18 years of age", "hardhats must be worn", "do not heat above 60°C", "hot surface" etc

• Our permanent printed warnings on, or close to, work equipment?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 23 - Markings

• Responsible

• Guidance
  Warnings must be clear, easy to understand, and unmistakable
  Warnings might be visible old Volvo for example flashing lights on equipment to prominent places like some control panels which can signal that something is broke down develop the phone or continues to be has it example flight reversing alarms on constructional refuse vehicles which one

• Are warnings clear, easy to understand and unmistakeable?<br><br>

  Yes

  No

  N/A

• Actions required

Action:

• Action from Regulation 23 - Markings

• Responsible

• ACOP: You should ensure that risks to the operator and other workers due to the mobile work equipment travelling are controlled. Workers should be protected against falling out of the equipment and from unexpected movement.

  Guidance: Consideration needs to be given to the following:-
  a) Ensuring wherever possible secure seating is provided
  b) Properly designed cabs, operators stations or work platforms
  c) Falling object protection
  d) Restraining systems
  e) Clear instructions for when passengers should or should not be carried

  ACOP: if work needs to be carried out during the journey the speeds should be adjusted as necessary
  Guidance: Mobile work equipment should be driven within safe limits. Speeds should be limited to avoid sudden movements.

  ACOP: You should ensure that guards and/or barriers fitted to equipment, which are designed to prevent contact with wheels and tracks, are suitable and effective.

  Guidance: Where there is a foreseeable risk there must be adequate separation provided between persons and wheels/ tracks

• Is the equipment suitable for carrying persons and does it incorporate features to reduce risks, including those from from wheels and tracks?<br>

  Yes

  No

  N/A

• What action is needed?

action

• Action

• By whom?

• When?

26.1 Rolling over

• ACOP:
  ROPS roll- over protection systems
  You should fit suitable roll-over protective structures to mobile work equipment where necessary to minimise the risks to workers carried, should roll-over occur.
  Restraining systems
  You should provide restraining systems on mobile work equipment, where appropriate, if they can be fitted to the equipment, to prevent workers from being crushed between the any part of the work equipment and the ground, should roll-over occur.
  Tractors
  If a tractor is fitted with a ROP rather than a cab, a restraining system will be needed

• Is there a risk of mobile equipment rolling over during normal use.

  Yes

  No

  N/A

• Is the equipment fitted with Roll-over protection

  Yes

  No

  N/A

• Action if the equipment doesn't have a cab fit ROP

• Responsible person

• When?

26.2 Restraining system

• Is the use of the restraining system mandatory?

  Yes

  No

  N/A

• Action make mandatory

• Responsible person

• When by?

Regulation 27 - Overturning of Fork Lift Trucks

• ACOP: forklift trucks fitted with either a mast or rollover protective structure,(ROPS)you should provide restraining systems where appropriate if such systems can be fitted to the equipment, to prevent workers being carried from being crushed between any part of the truck and the ground, should it overturn.
  Guidance: The mast of a vertical masted FLT will generally prevent overturning by more than 90degrees. A variable reach truck can roll over more than 180degrees and would need a ROPS.
  If your risk assessment shows that an FLT can roll over in use, the operator could leave their seated position and be crushed. Using a restraining system e.g. Seat belt is required. Use of restraining systems is also mandatory on any FLT fitted with a ROPS.


• 27.1 Is the FLT adapted or equipped to reduce risk to safety from its overturning?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

• 27.2 Is use of the restraining system mandatory?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

• 28.1 Guidance: Access to starter keys, handles,etc, should be controlled and made accessible only to authorised people.

• Can the unauthorised start up and use of the self propelled equipment be prevented

  Yes

  No

  N/A

• Action

• By Whom?

• When?

28.2 Collisions -Safety precautions to prevent contact will be required, e.g. buffers, automatic means. Safe methods of working will also be needed.

• Can collisions between rail- mounted work equipment be controlled/ minimised ( where 2 or more items share the same track) by using safe working methods or automatic means of preventing contact?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

28.3 Field of Vision for safety? Guidance: Mirrors or more sophisticated visual or sensing facilities may be necessary, e.g. cctv, radar. The selection of the device should be considered in your risk assessment.

• If the drivers field of vision is inadequate to ensure safety, are there adequate devices for improving their vision so far as is reasonably practicable?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

28.4 Brakes to enable it to slow, stop and safely park will be needed. If there is significant risk associated with the failure of the main breaking device a secondary system should be provided.z

• Has all self propelled mobile work equipment been fitted with a suitable means of bringing it to a halt?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

28.5 Lighting? Factors to consider include, level of lighting, presence of other people, obstacles and ground conditions.q

• If the work equipment is to be used in dark places, then is it fitted with suitable/appropriate lighting to allow it to be safely used?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

28.6 In the event of a fire. ACOP: Where escape from equipment in the event of a fire could not be achieved easily you should ensure that fire fighting appliances are carried on that equipment. Guidance: This covers both fire from the equipment itself and any load being handled. Examples include tower cranes and MEWPS.

• Is suitable fire fighting equipment fitted if the work equipment carries or tows anything that might constitute a fire hazard?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

29.1 Automatic stopping Guidance: This covers equipment where the control has no physical link, e.g. radio control. As part of your Risk Assessment you will need to consider equipment movement, the person controlling it,and anyone else in the vicinity. You may need to consider alarms, flashing lights etc. If equipment is controlled manually then the controls should be the hold to run type.

• Does the equipment stop automatically when it leaves control range and does it incorporate features to guard against crushing and impact?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

• Guidance: Drive shaft should be supported on a cradle or other means to protect against damage when uncoupled. Drive shafts should not be rested on draw bars or dropped on the ground.
  If seizure could lead to the ejection of parts, measures should be taken, e.g. Slip clutch, shear bolt

• 30.1 Are suitable precautions in place to prevent damage to drive shafts in the event of work equipment seizure?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

• 30.2 Is the drive shaft safeguarded if it could become soiled or damaged by the ground when uncoupled?

  Yes

  No

  N/A

• Action

• By Whom?

• When?

• Is the equipment free from leaks or discharges?

  Yes

  No

  N/A

Actions to be added:

• Actions required

Action:

• Action from Regulation 23 - Markings

• Responsible

• Is the equipment marked with appropriate energy ratings? If so what are they?

  Yes

  No

  N/A

• Is equipment connected to either surface water or foul sewer? (Describe connection and discharge)

  Yes

  No

  N/a

• Does equipment generate any dusts, fumes or other emissions?

  Yes

  No

  N/a

• Does equipment require connection to electricity, air, gas, water or other supplies? if so, specify what they are (Including voltages pressures etc)

  Yes

  No

  N/a

• Does the equipment require any registration or approval prior to operation? (For example, registration of x-ray machine being used on site)

  Yes

  No

  N/a

• Site Manager

• Name/Sign:

  Sign

• Department Manager

• Name/Sign:

  Sign

• Maintenance Supervisor

• Name/Sign:

  Sign

• Operator representative/team leader or supervisor

• Name/Sign:

  Sign

• Financial controller

• Name/Sign:

  Sign

• Purchasing Representative

• Name/Sign:

  Sign
