Service trade test - revised

• Module 1 service jointing

• ENWL training academy

• Conducted on

  Date

• John lee

• Personnel

• SNE cut-out

  Yes

  No

  N/A

• Service breech joint 35mm CNE OF 4c 120 PILC

  Yes

  No

  N/A

• Live cut and straight joint 35mm PILC to 35mm SNE

  Yes

  No

  N/A

• 2 way service breech joint off waveform

  Yes

  No

  N/A

• SNE service breech joint

  Yes

  No

  N/A

• CNE service breech joint

  Yes

  No

  N/A

• SNE service live cut and straight joint

  Yes

  No

  N/A

• CNE service live cut and straight joint

  Yes

  No

  N/A

Polarity and ELI testing

• CNE cut-out correct polarity found?

  Yes

  No

  N/A

• CNE cut-out no neutral found?

  Yes

  No

  N/A

• CNE cut-out cross polarity found?

  Yes

  No

  N/A

• CNE cut-out dead found?

  Yes

  No

  N/A

• SNE cut-out correct polarity found?

  Yes

  No

  N/A

• SNE cut-out cross polarity found?

  Yes

  No

  N/A

• SNE cut-out No neutral found?

  Yes

  No

  N/A

• SNE cut-out DEAD found?

  Yes

  No

  N/A

• Correct ELI reading for CNE cut-out identified (max reading 0.35 Ohms)?

  Yes

  No

  N/A

• Correct ELI reading for SNE cut-out identified (max reading 0.80 Ohms)?

  Yes

  No

  N/A

Insulation resistance and continuity testing on 3c 25mm CNE

• Did they find short between 2 phases?

  Yes

  No

  N/A

• Did they find the cable healthy?

  Yes

  No

  N/A

• Did they find broken phase?

  Yes

  No

  N/A

Insulation resistance and continuity testing 3 x single phase 35mm CNE cables

• Were the 2 healthy cables found?

  Yes

  No

  N/A

• Was the cable with the dead short found?

  Yes

  No

  N/A

Testing on 4c mains cable

• Phase down found?

  Yes

  No

  N/A

• Healthy cable found?

  Yes

  No

  N/A

• No neutral found?

  Yes

  No

  N/A

• No earth found?

  Yes

  No

  N/A

• Phase and neutral cross found?

  Yes

  No

  N/A

• Cable dead found?

  Yes

  No

  N/A

• Phase to phase (weld) found?

  Yes

  No

  N/A

Course review

• Assessor so name

  Sign

• Assessor name

  Sign
