Stimulation / Wire Line Rig Up Checklist

Stimulation / Wire Line Rig Up Checklist

TES-MS-1063

Stimulation / Wire Line Rig Up Checklist

Document Number: TES-HS-1033

Revision Level: 1.0

Release Date: 03/28/2013

• Customer Location

• Date (mm/dd/yy)

  Date

• Arrival Time (24 hours)

  Date

• Departure Time (24 Hours)

  Date

• Name

• Field Supervisor

Note: This form must be submitted to Division HSSE Specialist & Corporate QHSSE Manager prior to pumping stage 1.

Inspection Items

HSE

• Emergency contact numbers, ERP, GPS and directions posted in Data Van/Customer Trailer

  Safe

  At Risk

  N/A

• Appropriate JSEAs discussed and signed

  Safe

  At Risk

  N/A

• Sufficient absorbent materials on location to manage spills

  Safe

  At Risk

  N/A

• LO/TO equipment available

  Safe

  At Risk

  N/A

• Trip Hazards marked/eliminated

  Safe

  At Risk

  N/A

• Ground rods in place and equipment connected properly (Data Van, Shower trailer, Fuel Trucks)

  Safe

  At Risk

  N/A

• Line backers used to guard cables

  Safe

  At Risk

  N/A

• Adequate room for egress between equipment

  Safe

  At Risk

  N/A

• Wheels chocked on equipment with running road engines

  Safe

  At Risk

  N/A

• Confined spaces identified with placards

  Safe

  At Risk

  N/A

• MSDS available for every chemical on location

  Safe

  At Risk

  N/A

• MSDS available in shower trailer for quick reference

  Safe

  At Risk

  N/A

• Spill kits on location and available

  Safe

  At Risk

  N/A

• First Aid kits inspected and stocked

  Safe

  At Risk

  N/A

Backside (Blender, C.A.S., Hydration, Sand)

• Bridges used to keep hoses off sides of containment

  Safe

  At Risk

  N/A

• Acid Lines marked with Pink Ribbon

  Safe

  At Risk

  N/A

• Brine Lines marked with Orange Ribbon

  Safe

  At Risk

  N/A

• Chemical hoses marked at every connection and coded properly (Primary= 1 stripe, Back up= 2 stripes)

  Safe

  At Risk

  N/A

• Chemical hoses ran together to eliminate unnecessary trip hazards

  Safe

  At Risk

  N/A

• Suction hoses (Red) used on suction side

  Safe

  At Risk

  N/A

• Chemical hoses machine crimped or double banded

  Safe

  At Risk

  N/A

• Boost hoses (blue) used on discharge side

  Safe

  At Risk

  N/A

• Boost hoses restrained with whip check

  Safe

  At Risk

  N/A

• Unused ports on blender/hydration capped (discharge)

  Safe

  At Risk

  N/A

• Guards in place on Sand King stingers

  Safe

  At Risk

  N/A

• Chemical Exclusion Zone set up

  Safe

  At Risk

  N/A

• Respiratory Protection signs in place around sand area

  Safe

  At Risk

  N/A

• Shower Trailer set up within 55ft of Chemical area and function tested

  Safe

  At Risk

  N/A

• Water in shower trailer tested for Cl2 level

  Safe

  At Risk

  N/A

• Hand Rails set up on each mover

  Safe

  At Risk

  N/A

Front Side (Pumps)

• Pumps spotted with enough room for egress

  Safe

  At Risk

  N/A

• Pumps spotted with enough room for work platforms to extend

  Safe

  At Risk

  N/A

• Whip checks installed on boost hoses

  Safe

  At Risk

  N/A

• Restraints used for all independent pumps and lines from front of missile forward

  Safe

  At Risk

  N/A

• Iron certification within annual requirement

  Safe

  At Risk

  N/A

• Iron banded within quarterly date

  Safe

  At Risk

  N/A

• Swivel carriers available and used during rig up

  Safe

  At Risk

  N/A

• Fire extinguishers inspected and placed on front of tractors

  Safe

  At Risk

  N/A

• Lifting devices inspected and register up to date

  Safe

  At Risk

  N/A

• Fall arrest devices inspected and register up to date

  Safe

  At Risk

  N/A

• 75ft exclusion zone set up around pumping equipment and well head

  Safe

  At Risk

  N/A

• Exclusion zone marked off at front of pumps

  Safe

  At Risk

  N/A

Wireline

• Lifting equipment inspected and register up to date

  Safe

  At Risk

  N/A

• Fall arrest devices inspected and register up to date

  Safe

  At Risk

  N/A

• WL sheaves and chains inspected and register up to date

  Safe

  At Risk

  N/A

• BOP function test

  Safe

  At Risk

  N/A

• Hydraulic lines secured with whip checks

  Safe

  At Risk

  N/A

• Back of perforator outside of exclusion zone

  Safe

  At Risk

  N/A

• Catch pan under bottom sheave

  Safe

  At Risk

  N/A

• Perforator grounded

  Safe

  At Risk

  N/A

• Wheels chocked on perforator

  Safe

  At Risk

  N/A

Crane

• Confirm anti two block test

  Safe

  At Risk

  N/A

• Daily crane inspection forms available for review in crane cab

  Safe

  At Risk

  N/A

• Max 30 days inspections in cranes (all others brought back to yard for record keeping)

  Safe

  At Risk

  N/A

Checklist Completed By

• Name (Please Print)

  Sign

• Date/Time

  Date

• Comments

*Note: N2 Rig Up Checklist must be submitted along with this report if N2 is being used for operation.
