Title Page
-
Document No.
-
Audit Title
-
Client / Site
-
Conducted on
-
Prepared by
-
Location
-
Personnel
PROCEDURAL CHECKLIST
-
In use
TEST RESULTS
-
Attached to checklist
NON-CONFORMANCE
-
Identified by Contractor
NON-CONFORMANCE REPORT
-
Submitted
NOMINATED MATERIAL Clause R 40.5
-
Nomination of materials form R40.1 submitted
-
Nominated target grading received
-
Test dats to demonstrate compliance
-
Evidence of G 6 compliance
-
Representative samples received.
-
% passing grading serve sizes
-
CBR min 30 minus 19mm fraction.
-
Fine aggregate liquid limit max. 35
-
Fine aggregate plastic index max. 12.
-
Fines PI x% passing 0.425 max. 300
-
Hold point released for nomination
-
Hold point released for change to target grading.
AUDIT SAMPLE Appendix A3
-
% passing grading serve sizes
-
Grading ratio limits % passing
-
CBR min 30 minus 19mm fraction.
-
Fine aggregate liquid limit max. 40
-
Fine aggregate plastic index max. 16
-
Fines PI x% passing 0.425mm max. 350
CONSTRUCTION Clause R40.7
-
Underlying lot conforms
-
Material uncontaminated.
-
Layer maximum thickness 200mm
-
Density test results min. 95%
-
Pavement width
-
Uniformity and finish.
-
Hold point released top of course.
COMPLETED SURFACE Clause R40.8
-
Level, grade, shape as per design.
-
Completed surface toleranced
-
Tolerances satisfied -30 to +15mm
NON-CONFORMANCE
-
Identified by audit
-
Report requested.
-
Signature
