Rivergum Homes QA Inspection for Cladding

• Job Number

• Location
  Address

GENERAL

• Builder's Sign on site & visible

  Yes

  No

  N/A

• Bin on Site

  Yes

  No

  N/A

• Toilet is clean & tidy

  Yes

  No

  N/A

• Safety management plan check

  Yes

  No

  N/A

CLADDING

• Make sure the void scaffold is present & installed safely

  Yes

  No

  N/A

• All flashings installed (windows head etc.) & window stickers removed

  Yes

  No

  N/A

• Viscourse installed around all windows, corners, junctions & protruding 10m to base.

  Yes

  No

  N/A

• Cladding selection as per selections sheet & installed as manufacturer specifications

  Yes

  No

  N/A

• Check bushfire/ocean corrosion requirements

  Yes

  No

  N/A

• Corners & panels line up - string line to be used to ensure all cladding is level

  Yes

  No

  N/A

• All junctions to be finished as per details, clean & tidy & damp coursed appropriately

  Yes

  No

  N/A

• Nails to cladding etc. to be installed straight, in line & consistent

  Yes

  No

  N/A

• Joiners correct & installed

  Yes

  No

  N/A

• Cladding to start 25mm below the slab edge

  Yes

  No

  N/A

• Moldings as per plan

  Yes

  No

  N/A

• Sarking to walls

  Yes

  No

  N/A

• Air vents to base infill & clear of gas bottle location

  Yes

  No

  N/A

• Cladding to finish minimum 100mm above eave height

  Yes

  No

  N/A

• Adhesive joints filled, panels patched, sanded

  Yes

  No

  N/A

COLORBOND

• Cuts to be clean & tidy

  Yes

  No

  N/A

• Flashings as per plan

  Yes

  No

  N/A

• Control joints as per plan

  Yes

  No

  N/A

• Screwed off correctly

  Yes

  No

  N/A

• Channel to eaves installed after lining

  Yes

  No

  N/A

• Foam installed behind windows & corners

  Yes

  No

  N/A

• Check for any scratches and/or damage

  Select Yes No N/A

  • Yes
  • No
  • N/A

• Screws must line up, same colour & type

  Select Yes No N/A

  • Yes
  • No
  • N/A

• Gable vents installed

  Yes

  No

  N/A

• Screws must have neo's

  Yes

  No

  N/A

• Yes

  No

  N/A

MAXIWALL

• All exposed reinforcement coated (Hexicon)

  Yes

  No

  N/A

• 300mm damp course installed on slab to be trimmed to a 10mm protrusion from wall

  Yes

  No

  N/A

• Control joints installed (mastik on fire walls) - All fire walls to be fully sealed to ensure no gaps & no daylight to be seen

  Yes

  No

  N/A

• Top hat not to be continuous at control joints

  Yes

  No

  N/A

• Top hat runs relevant to wall heights

  Yes

  No

  N/A

• Temporary screw fixing/holes on boundary wall panels to be filled with fire rated silicone

  Yes

  No

  N/A

• Left over panels stacked at front for collection

  Yes

  No

  N/A

Acknowledgment

• I have read and understood the requirements of this audit based on Rivergum Homes policies & procedures

  Sign
