Title Page

  • Document No.

  • Conducted on

  • Prepared by

  • District

  • Unit Number

Check List

1. Pre-inspection / Service

  • 1.1) PJRA been completed and all appropriate controls in place.

  • 1.2) The unit is clean

  • 1.3) Does cuttings sizer have any standardize modifications?

  • Modification Summary:

  • Picture:

  • 1.4) LO/TO installed except when testing or when cord end is being inspected or serviced.

  • Service tech's initals

2. Electrical

  • 2.1) Inspect power cord and strain reliefs for cuts, gouges, exposed wires, pinches, kinks, pig tailing or any other damage.

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 2.2) Inspect cord end interior for water damage, corrosion, arching damage, melting, burn damage and all that all wires are correctly and firmly in place.

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 2.3) Cord end reassembled with all components correctly in place

  • 2.4) Inspect junction box interior for water damage, corrosion, arching damage, melting, burn damage and all that all wires are correctly and firmly wired in place.

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 2.5) Inspect junction box for damage, cracks and correctly mounted an sealed (as per manufactures specs)

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • Does unit have built in control box? (steps 2.6 - 2.8)

  • 2.6) Inspect control box interior for water damage, corrosion, arching damage, melting, burn damage and all that all wires are correctly and firmly in place.

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 2.7) Inspect control box housing for damage, cracks and correctly mounted an sealed (as per manufactures specs)

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 2.8) Control panel powered up and functionality of control panel confirmed

  • Picture of Damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • Electrical inspection & service verified completed

  • Verifying tech sign off

3. Motor

  • Remove motor to complete inspection

  • 3.1) Motor shaft move freely and quietly by hand

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 3.2) Motor runs when plugged in

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 3.3) Coupler is proper operable condition

  • Picture of damage:

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 3.4) Shaft cleaned and coupler can be adjusted on shaft as required

  • 3.5) Fan is in proper operating condition and properly mounted

  • 3.6) Fan cover is in proper operating condition and properly mounted

  • Motor inspection & service verified completed

  • Verifying tech sign off

4. Speed Reducer

  • 4.1) Inspection plug removed and couple tolerances verify

  • Remove speed reducer to complete inspection

  • 4.2) Motor drive shaft move freely by hand and output shaft turns

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 4.3) Verify housing paint is not discolored due to heat

  • Damage Summary:

  • Picture of damage:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • Speed reducer inspection & service verified completed

  • Verifying tech sign off

5. Body and Cutters

  • 5.1) Drive shaft moves freely when using wrench to turn

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 5.2) Drive shaft does not move up or down

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 5.3) Housing free of obstructions

  • 5.4) Tolerances on driven gear and drive gear correct

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 5.5) Driven shaft does not move up or down

  • Damage Summary:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 5.6) Tolerances on teeth and spacers are correct and are in good operating condition

  • Damage Summary:

  • Picture of cutters:

  • Inform supervisor of damage.

  • Supervisor: Does cutters require replacement?

  • Supervisor sign off:

  • Technician's repair notes:

  • Task completed

  • Picture of cutters:

  • Tech initials verified repairs completed

  • 5.7) Flange faces clean or necessary fittings properly installed

  • 5.8) 6 bolts on bottom of body housing tight

  • 5.9) Gear housing filled with grease and cover properly mounted

  • Body and cutters inspection & service verified completed

  • Verifying tech sign off

6. Frame

  • 6.1) Frame is properly squared

  • Damage Summary:

  • Picture:

  • Technician's repair notes:

  • Task completed

  • Tech initials verified repairs completed

  • 6.2) Frame and mounting base is free of cracks, gouges, broken welds or any structural damage

  • Damage Summary:

  • Technician's repair notes:

  • Picture of repair:

  • Task completed

  • Tech initials verified repairs completed

  • 6.3) Lifting bracket are correct and in proper operating condition

  • Damage Summary:

  • Picture of damage:

  • Technician's repair notes:

  • Task completed

  • Picture of operable lifting brackets:

  • Tech initials verified repairs completed

  • 6.4) Body housing correctly mounted and all 4 bolts tighten

  • Does unit have control panel mounted? (steps 6.5)

  • 6.5) Control panel correctly mounted

  • Does unit have cord hanger? (steps 6.6)

  • 6.6) Cord hanger correctly mounted

  • 6.7) Motor mount in proper condition, properly mounted and 2 bolts tightened

  • 6.8) Speed reducer and motor properly reinstalled

  • Frame inspection & service verified completed

  • Verifying tech sign off

7. Testing

  • 7.1) Unit plugged in tested for a minimum of 10 mins

  • 7.2) Unit cutters spins freely

  • Damage summary:

  • Technician's repair notes:

  • Task Completed

  • Tech initials verified repairs completed

  • 7.3) Teeth rotation correct

  • 7.4) Unit free of any unusual or loud noises

  • Damage summary:

  • Technician's repair notes:

  • Task Completed

  • Tech initials verified repairs completed

  • Does unit have control panel mounted? (steps 7.5 - 7.6)

  • Use long 2x4 to jam unit

  • 7.5) When jammed unit stops and reverses

  • 7.6) When jammed 3 times unit faults out

  • Testing inspection and service verified completed

  • Verifying tech sign off

8. Completion and Paint

  • 8.1) Frame top cover properly mounted

  • 8.2) Unit number weld on unit number:

  • 8.3) All unnecessary items, wires, bolts etc removed

  • 8.4) Unit paint matches BOS painting standards and represents BOS professionally

  • Completion and paint inspection & service verified completed

  • Verifying tech sign off

9. Supervisor Final Inspection

  • Have supervisor complete below listed final inspection and final sign off.

  • 9.1) Unit is clean

  • 9.2) Paint and identification meets BOS standards and current procedures

  • 9.3) All required fittings (if applicable) are present and in operable condition

  • 9.4) All cam locks and hammer unions (if applicable) are plugged or capped and has double securement in place as required

  • 9.5) Unit is ready to ship to field

  • 9.6) Take pictures of both of the ready unit's sides and weld on unit number

  • 9.7) Supervisors signature
