Title Page
-
Site conducted
-
Conducted on
-
Prepared by
-
Location
Roof
-
Edge protection<br>
-
Access ladders and platforms<br>
-
Parapet walls and concrete plinths<br>
-
Anchorage Points<br>
-
Waterproofing<br>
-
Expansion joints Penetrations<br>
-
Drainage<br>
-
Water pipe insulations<br>
-
Wall painting<br>
-
Wall cracks<br>
-
Non serviciable items<br>
Lighting arresters
-
Conductor installation<br>
-
All connections secured at joints<br>
-
Lighting rod is properly secured at the base<br>
Exterior surfaces
-
Façade and frame works
-
Stucco<br>
-
Glazing and windows <br>
-
Penetrations <br>
-
Shades properly secured anchored, including foundations.<br>
-
Claddings secured<br>
-
All post protectors corner guards in place<br>
-
All floor levels maintained with DUDC guidelines of 5mm<br>
-
Ramp wheel chair access as per DUDC guidelines<br>
Classrooms
-
Fire evacuation plan well placed and clearly marked ' YOU ARE HERE'
-
Wall painting<br>
-
Flooring<br>
-
Sharp edges protected<br>
-
All glass panels are visually protected <br>
-
Finger guards for doors<br>
-
Electrical outlets PAT tested with stickers<br>
-
All electrical sockets to be covered in KG and foundation sections<br>
-
Fire Safety / partitions / storage<br>
-
Light condition<br>
-
Windows secured and sealed<br>
-
Moisture/ ceiling mildews<br>
-
Proper circulation of AC <br>
-
Grills cleaned<br>
-
Air temp and humidity levels
-
Fresh Air supply if available<br>
-
Exhuast available <br>
Library
-
Ceiling <br>
-
Book shelves<br>
-
Wall covering <br>
-
AC<br>
-
Fire extinguishers in place<br>
-
Furnitures well placed<br>
-
Flooring<br>
Music room
-
Flooring
-
Wall sound proofing
-
Storage
-
AC
-
Cieling
-
All instruments are safety placed
Students toilets
-
Ceiling water leak
-
WC flush tank
-
Mirror
-
Water taps
-
Exhaust
-
Cleaning schedules
-
Toilet main door
-
Cubicle doors
-
Tissue holder
-
Garbage bin
-
Handtowels
Science labs
-
Gas isolation switch key operated
-
Emergency bells
-
Extinghishers
-
Sand buckets
-
Eye wash station has sufficient pressure
-
Over head shower functional
-
Exhaust for chemical storage containers<br>
-
Chemical storage has dedicated AC units<br>
-
Exhaust for fume hoods<br>
-
Bunsen burner and pipes<br>
-
False ceiling secured<br>
-
Gas leak detector in place
DT labs
-
All labs are safe to operate and fitted with guard and protection<br>
-
All equipments are connected to emergency switches and also a master swtich at the teachers desk<br>
-
All equipment's operation manual is well placed. <br>
-
Exhaust at cutting devices<br>
-
Antislip near working area<br>
-
Exhaust for laser cutting machine<br>
-
Sufficient lighting<br>
Public area internal
-
Easy access to school entrance no sharp corners, trip hazards, <br>
-
Sufficient landing between the main entrance doors and steps <br>
-
All glass doors and aluminium doors well secured on pivots and closer mechanism, these are checked at regular intervals<br><br>
-
Sufficient clearanced is maintained at main door from floor to avoid rubbing floor<br>
-
Signages are ear marked for offices, toilets and other areas<br>
-
Detectors functonal with pulse indications<br>
-
All control panels visible and functional at recption area ( fire alarm, gas panel)<br>
-
All possible places to install no hold door closers for glass doors<br>
-
Public area external
-
Check in at guard room sufficient place for visitors to sign in register<br>
-
Visitor entry register are in good condition not shatered and worn out<br>
-
Sufficient shading for visitors to sign in <br>
-
Assembly points are well placed and directed<br>
-
Access from Car parks to school building surroundings are clear and clean<br>
-
Access motorised gates are well maintained regularly <br>
-
Way signs from car park or entrance to required destinations
-
All hill curbs manholes painted and in clean conditions in level without any trip hazard<br>
-
Bollard lights cleaned and aligned<br>
-
Entrance door push pull signs<br>
-
Sufficient clearance is maintained between door and handle to avoid finger strike<br>
-
Aluminium door frames areas between moving and stationary are cleaned brushes in place air leaks sealed<br>
-
All grills at carpark area well painted off from rust, any crack repairs leakges are attended periodically<br>
-
All boundary lights are installed and working<br>
-
Pavement tiles are in level and proper separation from plot limits<br>
-
Privacy screen where ever required are in place<br>
-
Shades pergolas are in good conditions with all steel ropes in place<br>
-
Water coolers are covered and inside surroundings clean, installed for high grade filters<br>
-
All electricals cables/ CCCTV cables/AC pipes well concealed in GI trunking and not visible<br>
-
Tall trees well secured/ no trip hazards<br>
-
Car Parks and other areas well illuminated during nights <br>
-
Motion Sensors on and functional for basement parkings<br>
-
All entries and exit areas are well lit during darkness<br>
-
Building illumination lights are functional<br>
-
Lights at entrance to reception <br>
-
School flags<br>
-
Waste collection bins<br>
-
Recycle bins<br>
-
Security cabin<br>
-
Waste collection bins<br>
-
Recycle bins<br>
-
Wall painting
-
Wall cracks<br>
-
Non serviceable items not to be stored<br>
-
External flooring<br>
Storage rooms
-
All items inventory including tools
-
All storages room has to be marked with yellow round stickers to ensure its always locked<br>
-
Storage should be well organised with proper shelving maintaining a clearance of 1mt from the ceiling<br>
-
Storage are well ventilated<br>
-
Non servicable items not to be stored<br>
-
Combustible items/ Acid and corrosive items to be stored seprately with proper ventilation and indentifcaiton (MSD to be displayed<br>
-
Chemical labs storages should have proper ventilatio for chemical cupboards exhaust on 24/7 to be checked regularly<br>
Reception area
-
Furnitures well placed
-
Rulers pictures well displayed within guidelines
-
AC grills lights cleaned and working<br>
-
Indoor plants well nourished and trimmed<br>
-
All glass panels doors are cleaned <br>
-
Entire area well lit<br>
-
Visitors seating in good order, walls painted with students art work display<br>
-
Visitors area separate area marked for seating for people with determination <br>
-
Visitors toilets cleaned with proper cleaning check list schedules<br>
-
Reception area temp well maintained with contiunous air flow<br>
Students canteen
-
All Areas are well cleaned before and after service<br>
-
If kitchen in use inventory has to be carried out with regards to applicances used<br>
-
Checks on school appliance and appropraite maintenance to be carried out<br>
-
Canteen is ventilated and temp controlled <br>
-
All furnitures are safe to use without sharp corners splinters no sharp metal turnouts<br>
-
Sufficient fly o killers are in place<br>
-
Pest control as per schedule<br>
-
Cleaning as per schedule<br>
-
No storage items in the seating area<br>
-
No Cardboard boxes in Canteen<br>
-
Grease trap cleaned <br>
Staff canteen
-
All staff pantry are well cleaned <br>
-
Flooring in good order<br>
-
Sink tops are clear of water moisture<br>
-
Splash guard around sink to avoid water seepage into the cabiner to avoid fungus or mold <br>
-
Electrical outlets not overloaded with adaptors<br>
-
Fly O killer in place and maintained <br>
-
Fire extinguishers in place<br>
-
All food items cleared and areas disinfected to avoid infestation of pests<br>
-
Ventilation system to avoid food smell<br>
-
Grease trap cleaning contract where ever provided<br>
Staff toilet
-
Cileing water leaks<br>
-
WC flush tank<br>
-
Mirror<br>
-
Water taps<br>
-
Exhaust<br>
-
Cleaning schedules<br>
-
Toilet main doors<br>
-
Cubicle doors<br>
-
Tissue holder<br>
-
Garbage bin<br>
-
Handtowels
-
Corridors
-
All corridors and free of exit during fire evacuation or any emergencies
-
Fire hose cabinets are clear off any storages at 1.5mts around each stations and well marked<br>
-
Zone control valves are well marked just below false ceiling<br>
-
Entire area well lit and sensors on with emergency lights at regular intervals <br>
-
Floor coverings well in place all joints secured expansion joints caps secured on walls<br>
-
Wall coverings, ceiling tiles, Corridor painting/skirtings<br>
-
All grills and light fitting cleaned<br>
-
Cabinets/ Display boards well secured in corridor<br>
Staircase
-
Equipped with EVAC chair
-
Step edges has antislips in grooves or antislip 3M tapes<br>
-
Handrail secured to floor or wall <br>
-
Stair case pressuring units functional (wherever provided)<br>
Lifts
-
Elevator car conditions, well lit, fans operational <br>
-
Floorings clean and in good order<br>
-
Elevator connected to CDA 24/7<br>
-
Emergency landing device funtional in case of power failure<br>
-
Elevator Alarm and intercom operational <br>
-
Adequate training provided to school staff and security for evacaution in case someone stuck<br>
Swimming pool and pump room
-
Entry exit restricted /Access control in place<br>
-
Fire evacuation in place<br>
-
Pool notices in english and arabic<br>
-
Pool deck area has no stagnant water <br>
-
life rings <br>
-
spinal board
-
provision of telephone landline<br>
-
Board with written information for ambient temp, pool temp, chemical level, <br>
-
Pool steps<br>
-
Depth Marking<br>
-
Circulation pump & filters<br>
-
Replacement of filter media sand after certain duration time and in case issues with pressure <br>
-
Ventilation, extraction, louvres<br>
-
heater / heat Pumps<br>
-
Chemical Dosing Unit<br>
-
Filtration Pump<br>
-
Water leakage in pump room
-
Float Switch
-
Underwater light leak tests
-
Make-up Tank<br>
-
Pool shock treatment<br>
-
Chemical level log<br>
-
Pool gates secured<br>
-
Pump room secured<br>
-
Pool finish and waterproofing<br>
Foot ball pitch
-
Pitch condition
-
Goal posts
-
Goal post protection
-
Fence secured
-
Fence end wires trimmed
-
Pole lights for pitch
Tennis court
-
Floor conditions
-
Floor line marking
-
Post net conditions
-
Lights in court
-
Gym
-
Gym curtains
-
Gym flooring
-
Gym AC
-
Exit doors
-
Gym lights
-
Gym changing rooms
-
Bleechers
-
Roof in good condition water seal
-
Crash mats on wall
Play area external
-
Equipment condition with no sharp objects
-
No gaps in wood
-
Floor surface well protected
-
Trip hazards
Play area internal
-
Equipments conditions with no sharp objects in case of wood no gaps<br>
-
Floor surface <br>
-
Trip hazards<br>
Signages
-
All such areas are locked and access restricted<br>
-
All Exit signs well displayed with legends<br>
-
Assembly points at all places for quick identificaton<br>
-
Locating fire hose reels and extinguisher<br>
Fire Alarm System<br>
-
Alarm Panel healthy condition<br>
-
Fire panels are connected to 24/7 CDA monitoring system <br>
-
Manual setting off alarm after school hours and ensure alarm is heard at all areas<br>
-
Cabling are secured<br>
-
Detectors (to check after school hours manually)<br>
-
Call points vandal proof<br>
-
All areas covered with smoke detectors<br>
-
External hydrants protection<br>
-
Inspection dates on Fire extinguisher and hose reels<br>
-
Hydrostatic tests required for aging fire extinguishers<br>
-
Sprinkler position as per CDA requirements<br>
-
Changeover of Diesel pump in case of power failure<br>
-
Sufficient diesel level<br>
-
Zone control valves marked<br>
-
All access doors are interfaced with fire panels<br>
-
Sounders - Annunciators<br>
Fire sprinkler system
-
Tanks
-
All wet risers valves are open
-
Diesel fire pump including ventilation, exhaust, starter and battery charger
-
Diesel fuel tank
-
Diesel pump controller<br>
-
Jockey pump<br>
-
Electric fire pump<br>
-
Electric fire pump controller<br>
-
Automatic changeover panel<br>
-
Fire pump service record<br>
-
Fire pump test certificates<br>
-
Zone Flow switches and Valves (labelled and displayed)<br>
-
Pipe work, fixtures & fittings<br>
-
Pressure Gauges<br>
-
Fire Panel Connections from pressure switches, flow switches and valves<br>
Fire fighting
-
Breaching Inlet to be clear of all any items free access in case covered needs display<br>
-
Landing Valves need to be idendified<br>
-
Fire Hose Reels/Fire Extinguishers cabinets need to be identified and marked in fire escape plans<br>
-
Fire Hose Reels cabinets to be clear in and around 1.5mts and easy access <br>
-
Pillar Hydrants and Standpipes protection<br>
-
FM 200 Clean Agent System (if installed) monitor pressure in case triggered needs refilling<br>
Fire safety
-
Fire Doors<br>
-
Emergency Exits<br>
-
Staircases no storages and clear for easy access<br>
-
Fire Escapes<br>
Emergency Lighting<br>
-
Control panel<br>
-
Lighting Unit Location<br>
-
Cabling<br>
-
Emergency light levels<br>
-
Identifying dark spots in case of power failures especially toilets<br>
-
Illuminated emergency light exit signage<br>
BMS controlled
-
Airconditioning<br>
-
Lighting Control System<br>
-
Water level monitoring<br>
-
HVAC monitoring<br>
Power Distribution
-
Conduits, trays and trunking<br>
-
Cable connections and to fittings and/or equipment<br>
-
Earth electrode & Earth continuity<br>
-
Equipment labelling<br>
-
HV Electrical System & MDB<br>
-
DBs are in accordance to load schedule as approved by DEWA<br>
-
LV switch-room single line connection Diagrams<br>
-
External sockets are weather proof<br>
-
Sub DBs<br>
-
Power factor meter operational all capacitor banks functional <br>
-
Auto fire extinguisher<br>
-
Sub Meter<br>
Lighting
-
Lighting levels <br>
-
Luminaires (change over to LEDs)<br>
-
Light fittings<br>
-
Driver operated lights protection<br>
-
Timer Control System<br>
Gas Distribution System
-
LPG panel is interfaced with fire alarm system<br>
-
Gas sensor leak detector is checked as part of PPM<br>
-
LPG Tanks safety system sprinkler and Diluge functional<br>
-
Storage area safety<br>
-
Distribution pipe work<br>
-
Valves<br>
-
Sprinklers on tank<br>
-
Metering<br>
Sewer and Drain system
-
Periodic inspection of all Sewer lines<br>
-
Maintenance access to drainage pipes<br>
-
Holding Tank & Sewage pumps<br>
-
Manhole sleeves to basement<br>
-
Sewage Sump Pump<br>
-
Sewage/Sludge irrigation water Tank<br>
-
Storm & drain water system<br>
Airconditioning
-
Chiller clearance/condition, in case of outdoor unit check condenser clearance
-
Chiller cables secured/all sensors & transducers secured
-
Chiller safety cut outs functional<br>
-
Flow switches in place
-
Chiller display easily accessible
-
Access to chilled water pipes and valves<br>
-
Vapour seals<br>
-
Thermal insulation<br>
-
Ductwork & support<br>
-
Make up tank <br>
-
Chilled Water Pump<br>
-
Chilled Water Quality<br>
-
Chill water closed circuit<br>
-
FAHU (Fresh Air Handling Unit)<br>
-
AHU (Air handling Units)<br>
-
AHU motorised valves <br>
-
FCU (Fan Coil Units)<br>
-
FCU motorised valves <br>
-
Heat Exchanger
-
Pressurization Units<br>
-
Split/Condenser Units<br>
-
Air quality in the room<br>
-
Fresh Air supply into the room<br>
-
Air balancing and water balancing checked<br>
-
Random checks on humdity and temperature<br>
Telecomunicaiton
-
Mobile phone reception
-
Mobile towers in vicinity
Water tanks
-
Water tanks check for wall conditions <br>
-
Float valves are funcitonal and secured<br>
-
Frequency of cleaning <br>
-
Test reports<br>
-
Follow up on test reports in case of failures<br>
-
Booster pumps<br>
-
Pressurization Units<br>
-
Water treatment unit
-
Coolers/ UV system<br>
-
Water tanks secured<br>
-
All such areas are locked and access restricted<br>
-
Safety system<br>
-
Valves fixtures & fittings are holding <br>
-
Potable Water quality<br>
-
Various tests reports carried out as per DM guidelines<br>
-
Access for maintenance<br>
-
Potable Water Booster Pumps<br>
-
Garbage area provision for cleaning with pumps or pressure hose<br>
-
PRVs in place <br>
-
Gauges<br>
-
Potable Water Transfer Pumps<br>
-
Pressure Vessels<br>
-
Water Treatment System (if installed)<br>
-
Floor distribution manifolds<br>
-
Sufficient pressure is maintained across all end points<br>
O&M manuals
-
Statutory Body approvals for MEP, technical and engineering designs<br>
-
Schedule of materials & finishes and their maintenance requirements<br>
-
Approved as-built drawings<br>
-
Common area asset register, drawings and spare parts schedule<br>
-
Provision and identification of meters for the building and common areas<br>
-
Current meters reading for electricity, chilled water, gas, and water as applicable<br>
-
Warranty and Guarantee documents<br>
-
Completion Certificates and support documents<br>
-
Statutory signage is installed and documented<br>
Maintenance
-
Maintenance activity logs<br>
-
PPM logs copy
-
Emergency calls log<br>
-
Third party safety Audit on lifts<br>
-
Previous 12 months fire systems test & inspection results<br>
Landscaping
-
Has to be appealing with lively plants and shrubs<br>
-
Monitoring of water conditions in case of TSE<br>
-
Identifying potential dangerous plants <br>
-
Health and safety issues with thorns or barks<br>
AOB
