EWI Quality Assurance Report

General

• Conducted on

  Date
• Location
  Address

• Prepared by

  Select Dean Calcutt Shakeel Khanzada Waqar Ahmed Josh Heatherwick Joel Apps Hamed Gazori Shaheer Abdulkarim

  • Dean Calcutt
  • Shakeel Khanzada
  • Waqar Ahmed
  • Josh Heatherwick
  • Joel Apps
  • Hamed Gazori
  • Shaheer Abdulkarim

• Client

  EON GFS

  OVO

  United Living

  ECO 4

EWI System Details

• Manufacturer

  STO

  Insta

  Wetherby

  Licata

  EWI PRO

• System Name

  Select EPS Silicone Finish EPS Brick Effect EPS Brick Slip EPS Acrylic Slip Mineral Wool Silicone Finish Mineral Wool Brick Effect Mineral Wool Brick Slip Mineral Wool Acrylic Slip Other

  • EPS Silicone Finish
  • EPS Brick Effect
  • EPS Brick Slip
  • EPS Acrylic Slip
  • Mineral Wool Silicone Finish
  • Mineral Wool Brick Effect
  • Mineral Wool Brick Slip
  • Mineral Wool Acrylic Slip
  • Other

Climate

• Weather Conditions

  Select Sunny Overcast Drizzle Rain Stormy Frost Snow

  • Sunny
  • Overcast
  • Drizzle
  • Rain
  • Stormy
  • Frost
  • Snow

• Temperature

• Humidity

Design

• Is the retrofit design in place and on site

  Yes

  No

  N/A

• Does the installation match the details in the retrofit design

  Yes

  No

  N/A

• Has the lead installer been briefed on the retrofit design requirements

  Yes

  No

  N/A

Stage

• Please highlight which stage is being inspected (N/A any other stages that are not available to inspect)

  Preparation

  Boarding

  Base Coat

  Top Coat

• Please capture as many evidence pictures in the report as possible and make comment where necessary to support ongoing compliance

Preparation

• Substrate inspected and appropriate for Boarding

  Yes

  No

  N/A

• Services extended to take EWI system thickness

  Yes

  No

  N/A

• Roofline and system overhangs sufficient for EWI >40mm

  Yes

  No

  N/A

• Ground and window protection in place

  Yes

  No

  N/A

Boarding

• Starter track level and straight

  Yes

  No

  N/A

• Seal tape installed behind starter track

  Yes

  No

  N/A

• Bedding adhesive applied correctly where required

  Yes

  No

  N/A

• Boards staggered and no straight joints (inc. 200mm 'L' around windows & doors)

  Yes

  No

  N/A

• Correct number of fixings per board

  Yes

  No

  N/A

• Fixings driven correctly (not overdriven)

  Yes

  No

  N/A

• Extra fixings placed around openings

  Yes

  No

  N/A

• Boards rasped level

  Yes

  No

  N/A

Base Coat

• Base coat mixed correctly

  Yes

  No

  N/A

• Thickness of base coat acceptable

  Yes

  No

  N/A

• Mesh installed and overlapping

  Yes

  No

  N/A

• Stress patches in place (200mmx200mm)

  Yes

  No

  N/A

• Corner beads installed level and plumb

  Yes

  No

  N/A

• Base coat evenly applied allowing for level top coat

  Yes

  No

  N/A

Finishing Coat

• Walls primed ready for top coat application

  Yes

  No

  N/A

• Top coat mixed correctly

  Yes

  No

  N/A

• Thickness of top coat acceptable

  Yes

  No

  N/A

• Top coat evenly applied

  Yes

  No

  N/A

• Finish coat satisfactory and free from scars

  Yes

  No

  N/A

• Brick slips installed with correct spacings

  Yes

  No

  N/A

• Brick effect render cut in with correct spacings

  Yes

  No

  N/A

• Has silicone sealant been applied to all openings, joints and abutments

  Yes

  No

  N/A

Summary

• General notes and summary of findings

Audit Signoff

• Name and signiture

  Sign
