WUC - Timber Wall Frame (Checklist)

• Site conducted

  Select

• Conducted on

  Date

• Prepared by

• Location
  Address

Westurban finishing and design Requirements

• Ground floor wall height as per Frame scope of work

  Yes

  No

  N/A

• First floor wall Height as per Frame Scope of work

  Yes

  No

  N/A

• Ground floor Internal Door heights as per C&M

  Yes

  No

  N/A

• First floor Internal Door height as per C&M

  Yes

  No

  N/A

• Window Head height as Per Scope of works

  Yes

  No

  N/A

• Window work as Kitchen splash back / Sill height 860 mm

  Yes

  No

  N/A

• Windows work as Kitchen Splash back, location match with Kitchen Cabinet layout

  Yes

  No

  N/A

• Window required Privacy with clear glass Windowsill height 1670 mm (Clear Glass 1720 mm from structural floor)

  Yes

  No

  N/A

• Check all internal dimensions to each room

  Yes

  No

  N/A

• Stairwell is correct dimensions (as per plan)

  Yes

  No

  N/A

Wall Framing

• Check that wall and truss framing has not been damaged - during delivery

  Yes

  No

  N/A

• Check for all columns that they are plumb, straight, and square

  Yes

  No

  N/A

• Check that windows are of even height and brick cladding area head height as per WU scope of works to match with brick courses

  Yes

  No

  N/A

• House frame plumb, square and straight ( Posts and wall frames are defective if they deviate from vertical by more than 5 mm over a 1.8 m height.)

  Yes

  No

  N/A

• Check that there are double/Trible studs to under all girder trus ses, Beams and Lintel support locations

  Yes

  No

  N/A

• Top plates are straight

  Yes

  No

  N/A

• Bracing as per engineering drawings/Install Guideline

  Yes

  No

  N/A

• Tie Down Concrete slab as per requirement

  Yes

  No

  N/A

• Check frame overhang of slab (max 10mm)

  Yes

  No

  N/A

• Check that all bottom plates to door openings are cut out

  Yes

  No

  N/A

• Comments
